Brand New Holland Tractors
Series TX Series Tractors
No. Of Cylinders 4
HP Category 75 HP
PTO HP 69
Gear Box Partial Synchromesh
Brakes Oil Immersed Multi Disc Brakes


Key Specifications Of New Holland 5630 TX Plus 4WD

Tractor HP
Tractor HP
75 HP
Wheel Drive
Wheel Drive
4WD
Clutch
Clutch
Double Clutch with Independent PTO Lever
Gear Box
Gear Box
Partial Synchromesh
Steering
Steering
Power Steering
Lifting Capacity
Lifting Capacity
2000

About New Holland 5630 TX Plus 4WD

New Holland 5630 Tx Plus Trem IV 4WD price in India starts from Rs. 16,20,000* (Ex-Showroom). It is a 75 HP tractor model.

New Holland 5630 Tx Plus Trem IV Engine

New Holland 5630 Tx Plus Trem IV 4WD is powered by a 4-cylinder, HPCR TREM IV engine. It delivers a power output of 75 HP @ 2300 RPM. This tractor comes fitted with a dual element dry type air filter and a liquid-cooled system.

New Holland 5630 Tx Plus Trem IV Transmission

This tractor is available with a double clutch (IPTO) and a partial synchromesh gear box. The gear speeds include: 12 forward + 3 reverse (UG) / 12 forward + 3 reverse (creeper). The gear lever position is side shift. It also features a heavy-duty hub reduction rear axle.

New Holland 5630 Tx Plus Trem IV Brakes & Steering

This New Holland tractor model comes with oil-immersed multi-disc brakes and a power steering.

New Holland 5630 Tx Plus Trem IV PTO & Hydraulics

The PTO HP of this tractor is 69 HP.  It comes with a standard PTO speed of 540 @ 1800 ERPM with the option of GSPTO/RPTO.

It features Sensomatic24 hydraulic lifting that offers a lifting capacity of 2000 kg. The tractor also has a dual remote/auxiliary valve.

New Holland 5630 Tx Plus Trem IV Tyre Sizes

The front tyre size of the tractor is 12.4 X 24, whereas the rear tyre size of the tractor is 18.4 X 30.

New Holland 5630 TX Plus Trem IV Weight & Dimensions

The weight of the tractor is 2835 kg. It comes with a ground clearance of 435 mm and a wheelbase of 2045 mm.

New Holland 5630 Tx Plus Additional Features

  • This tractor comes with a 6-year transferable warranty and 600-hours of service interval.
  • It has a fuel tank capacity of 70 litres.
  • It features multiple engine modes, DRL, ROPS with Canopy, Front Fender and a telescopic stabilizer.

Rivals

Mahindra Novo 755 DI PP 4WD V1 and John Deere 5075 Gear Pro 4WD Trem IV are some of the main competitors of the New Holland 5630 TX Plus 4WD.

What is New Holland 5630 TX Plus 4WD Price in India 2025?

New Holland 5630 Tx Plus Trem IV 4WD price in India starts from Rs. 16,20,000* (Ex-Showroom). However, it is important to note that the on-road price of the tractor may vary state wise according to RTO charges, insurance, road taxes, etc.

You can get more information on tractor loan facility, so you can view a tractor of your preference with easy EMI options.

Why Choose Tractorkarvan to Get More Information on New Holland 5630 TX Plus 4WD?

Tractorkarvan is your most reliable online platform to get information regarding New Holland tractors including the New Holland 5630 TX Plus 4WD. On our website you can get the latest updates on tractor prices, specifications, unique features, informative videos & images, user reviews and much more. You can also use the Compare Tractor Tool to compare different New Holland tractors according to their HP and price.

If you’re seeking a more budget friendly option, visit the used tractor page and check out second hand tractors listed on the website in excellent condition.

Read More

New Holland 5630 TX Plus 4WD Engine

No. Of Cylinders 4
HP Category 75 HP
Engine Type FPT S8000, 12 Valve HPCR Engine
Engine Rated RPM 2300 RPM
Air Filter 8 Inch Dual Element, Dry Type
Cooling System Liquid Cooled
Fuel Type Diesel

New Holland 5630 TX Plus 4WD Transmission

Clutch Double Clutch with Independent PTO Lever
Gear Box Partial Synchromesh
Gear Speed 12F+3R (Creeper) / 12F+3R (UG)
Gear Lever Position Side Shift
Brakes Oil Immersed Multi Disc Brakes
Rear Axle Heavy Duty Hub Reduction

New Holland 5630 TX Plus 4WD Steering

Type Power Steering

New Holland 5630 TX Plus 4WD Power Take Off

PTO HP 69 HP
PTO Speed 540 & GSPTO or RPTO

New Holland 5630 TX Plus 4WD Fuel Capacity

Capacity 70 Litres

New Holland 5630 TX Plus 4WD Hydraulics

Lifting Capacity 2000 kg
Remote / Auxillary Valve Dual

New Holland 5630 TX Plus 4WD Tyre Size

Wheel Drive 4WD
Front 12.4 X 24
Rear 18.40 X 30

New Holland 5630 TX Plus 4WD Dimensions And Weight

Total Weight 2835 kg
Wheel Base 2045 mm
Overall Length 3780 mm
Overall Width 2000 mm
Ground Clearance 435 mm

New Holland 5630 TX Plus 4WD Electrical

Battery 100 Ah
Alternator 55 Amp

New Holland 5630 TX Plus 4WD Safety Features

ROPS Yes

New Holland 5630 TX Plus 4WD Other Information

Accessories Telescopic Stabilizer
Additional Features Remote Valve upto 4 Ports, Swinging Drawbar, ROPS with Canopy, Front Fender

New Holland 5630 TX Plus 4WD Variants

You can find the variants of New Holland 5630 TX Plus 4WD available on Tractorkarvan with complete specification & prices. Total variant's available 1.

TractorKarvan Take On New Holland 5630 TX Plus 4WD

Good Things
  • FPT HPCR engine with 3 engine modes.
  • 600 hours of service interval.
  • 600 hours of service interval.
  • Bolder and modern looks with enhanced ergonomics.
Could be Better
  • Could have offered a fully synchromesh gearbox.
  • An option for planetary gear reduction could’ve been provided.

New Holland 5630 TX Plus 4WD Verdict

The New Holland 5630 TX Plus 4WD is a solid choice for farmers to perform heavy-duty operations. This tractor works efficiently with a wide range of heavy implements. It comes fitted with a 75 HP TREM IV engine, which offers high torque and multiple driving modes. This ensures higher pulling power and easy operation in rugged terrains while showcasing fuel efficiency at the same time. The Sensomatic24 lift offers a high lifting capacity for best hydraulic operation. It also comes with an independent clutch lever and multiple gear speed options for the smoothest operation on the field. All these features, combined with a 600-hour service interval, make it a great option for farmers seeking an affordable, fuel-efficient and low-maintenance tractor under this HP range.
