Tata Ace Specification

Tata Ace

Be the first to rate Add Review
₹4.50 - ₹7.19 Lakh*
EMI starts @ ₹11372/month

About Ace

The Tata Ace mini truck is available in 4 variants. This Diesel mini truck produces 14.7 - 26 KW of power . It has a GVW of 1460 - 2905 Kg and wheelbase of 1800 - 2250 mm.

Read More

Key Specifications Of Tata Ace

PTO HP Power
14.7 - 26 KW
Commercial Vehicles Engine Engine
694 - 798 CC
gvw HP GVW
1460 - 2905 Kg
payload HP Payload Capacity
750 - 1100 Kg
tyres HP Number Of Tyre
4
wheelbase HP Wheel Base
1800 - 2250 mm
fuel HP Fuel Type
Diesel

Tata Ace Specifications & Features

Max Power 14.7 KW
Capacity 702 CC
Engine Rated RPM 3600 RPM
Emission Norms BS VI
Max Torque 160 Nm
Mileage 22 Kmpl
Gradeability 27 %

Clutch Single Plate, Dry Type, Mechanical Actuation
Gear Speed 4 Forward + 1 Reverse
Max Speed 65 Kmph
Steering Type Mechanical , Variable Ratio

Capacity 30 Litres

Tyre Size 145R12 LT 8PR
Tyre Type Tubeless

Overall Length 3800 mm
Overall Width 1500 mm
Overall Height 1845 mm
Ground Clearance 160 mm
Turning Radius 1675 m
Wheel Base 2100 mm
GVW 2905 Kg
Loading Length 2200 mm
Loading Width 1490 mm
Loading Height 300 mm

Rear Suspension Parabolic Leaf Spring

Be the first to review the Tata Ace!

No reviews for the Tata Ace yet. Help others make informed decisions!

Write A Review

Similar Used Commercial Vehicles

Tata ACE Second Hand Commercial Vehicles
Tata ACE
2022 Mini Truck
₹2.02 Lakh* EMI ₹4,333/m
Get More Details
Salem, Tamil Nadu
Tata ACE Second Hand Commercial Vehicles
Tata ACE
2017 Mini Truck
₹1.33 Lakh* EMI ₹2,864/m
Get More Details
Surat, Gujarat
Tata ACE Second Hand Commercial Vehicles
Tata ACE
2019 Mini Truck
₹1.30 Lakh* EMI ₹2,793/m
Get More Details
Bengaluru Urban, Karnataka
Tata ACE Second Hand Commercial Vehicles
Tata ACE
2018 Mini Truck
₹0.75 Lakh* EMI ₹1,611/m
Get More Details
Bhavnagar, Gujarat
View All Used Commercial Vehicles

Tata Ace Comparison With Competitors

Tata Ace
VS
Mahindra Supro
Tata
Ace
From ₹7.00 Lakh*
Mahindra
Supro
₹6.58 - ₹7.19 Lakh*
Ace vs Supro
Tata Ace
VS
Tata Intra V10
Tata
Ace
From ₹7.00 Lakh*
Tata
Intra V10
₹6.75 - ₹7.51 Lakh*
Ace vs Intra V10
Tata Ace
VS
Maruti Suzuki Super Carry
Tata
Ace
From ₹7.00 Lakh*
Maruti Suzuki
Super Carry
₹5.06 - ₹6.12 Lakh*
Ace vs Super Carry
View All Commercial Vehicles Comparison

Tata Ace Variants

You can find the variants of Tata Ace available on Tractorkarvan with complete specification & prices.

Ace LS Diesel
From ₹7.00 Lakh*
Key Features
  • 14.7 KW
  • Diesel
  • 2905 Kg
Get More Details Compare
Ace Flex Fuel
From ₹5.51 Lakh*
Key Features
  • 22 KW
  • Petrol
  • 1460 Kg
Get More Details Compare
Ace CNG
₹4.50 - ₹6.69 Lakh*
Key Features
  • 22 KW
  • CNG
  • 1790 Kg
Get More Details Compare
Ace HT Plus
From ₹7.19 Lakh*
Key Features
  • 26 KW
  • Diesel
  • 2120 Kg
Get More Details Compare
