Tata LPT 710 3920 CAB Specification
Tata LPT 710 3920 CAB
₹16.32 -
₹18.28 Lakh*
Tata LPT 710 3920 CAB comes at a starting price of Rs. 1632000 (Ex-Showroom*) in India. This popular truck is widely used for transporting heavy goods and materials across long distances. Tata LPT 710 3920 CAB offers a mileage of 9 kmpl.
The engine type of Tata LPT 710 3920 CAB is Water Cooled Direct Injection with intercooler TCIC Engine, which allows it to generate a maximum power output of 75 kW. This truck generates the maximum power output at 2800 ERPM. it produces a maximum torque of 300 Nm, making the truck suitable for heavy-duty tasks.
The clutch offered in this truck is Single Plate dry friction type Its gearbox type is G400, Cable shift Machanism. This truck features 5 Forward + 1 Reverse gear speeds. The steering type in Tata LPT 710 3920 CAB is Power Steering (4 Spoke).
The mileage of this Tata LPT 710 3920 CAB truck is 9 kmpl. The fuel type of this truck variant is Diesel. It offers a fuel tank capacity of 90 litres. The DEF tank capacity is 18 litres.
The loading length and width of the truck are 5218 mm and 2135 mm, respectively. The loading height is noted to be 1825 mm.
The brakes type of this truck is Drum With Auto Slack Adjuster, which ensure reliable braking during emergencies. Its front suspension includes Parabolic Suspension with rubber bush and hydrualic double acting telescoping shock absorbers.
The total number of tyres in Tata LPT 710 3920 CAB is 6. The size of its front tyres is 8.25R16 16 PR Radial Low CRR Tyre (RR -2 - 1 Spare). The rear tyre is available in the size of 8.25R16 16 PR Radial Low CRR Tyre (RR -2 - 1 Spare).
The wheelbase of Tata LPT 710 3920 CAB is 3310 mm. Its ground clearance is 220 mm.
| No. Of Cylinders | 4 Cylinder |
| Max Power | 75 KW |
| Capacity | 2956 CC |
| Engine Rated RPM | 2800 RPM |
| Emission Norms | 4 SP BS6 Phase2 |
| Max Torque | 300 Nm |
| Fuel Pump Type | Inline, Delphi CR System |
| Mileage | 9 Kmpl |
| Gradeability | 34.7 % |
| Clutch | Single Plate dry friction type |
| Gear Box | G400, Cable shift Machanism |
| Gear Speed | 5 Forward + 1 Reverse |
| Steering Type | Power Steering (4 Spoke) |
| Differential Lock | No |
| Secondary Fuel Type | Diesel |
| Capacity | 90 Litres |
| DEF Tank Capacity | 18 Litres |
| Rear Tyre | 8.25R16 16 PR Radial Low CRR Tyre (RR -2 - 1 Spare) |
| Front Tyre | 8.25R16 16 PR Radial Low CRR Tyre (RR -2 - 1 Spare) |
| Ground Clearance | 220 mm |
| Turning Radius | 8.5 m |
| Wheel Base | 3310 mm |
| GVW | 7490 Kg |
| Loading Length | 5218 mm |
| Loading Width | 2135 mm |
| Loading Height | 1825 mm |
| FAW | 3640 KG |
| RAW | 3850 KG |
| Brakes Type | Drum With Auto Slack Adjuster |
| Front Suspension | Parabolic Suspension with rubber bush and hydrualic double acting telescoping shock absorbers |
| ABS | No |
| Rear Axle | Banjo Type - Single reduction htpoid gears, fully floating axle shafts |
| Regenerative Braking | No |
| Air Conditioning | No |
| Cabin Type | Fully Forward Cabin |
| Battery | 12 V, 100 Ah |
| Alternator | 120 A |
| Battery (Voltage) | 12 V, 100 AhV |
| Warranty | 3 Year or 300000 Km |
You can find the variants of Tata LPT 710 available on Tractorkarvan with complete specification & prices.
