Engine
Make
TATA
TATA
Emission Class
BSIII
Engine Model
497TC
497 TC48 (turbo intercooler)
Engine Type
4 stroke
Cooling System
Liquid-cooled
Engine
76 HP
76 HP
Engine Rated Speed
2200 RPM
2200 ± 100 RPM
Cylinder
4 Cylinder
4 Cylinder
Fuel Tank Capacity
100 L
120 L
Main Dimensions
Weight
5000 KG, 600 KG (Front Attachment)
4900 KG
Length
7185 MM (with front attachment), 5410 MM (without front attachment)
6450 MM
Width
2832 MM, 2015 MM (At transport), 1850 MM (Body width)
2850 MM
Height
3094 MM
3435 MM
Min. Ground Clearance
350 MM
Cutter Bar Mechanism
Effective Width
2415 MM
2600 MM
Threshing Mechanism
Threshing Principle
Tangential Axial Flow (TAF)
Offloading Rate
27 l/s
Threshing Roter Dia X Width
600 X 830 MM
450 X 560 MM
Upper Sieve
793 X 1443 MM
0.64 Sq m.
Lower Sieve
793 X 1443 MM
Swing Separator Size Sieve Box Width
1240 MM
Unloading System
Universal joint type
Cleaning system
Type
Force air-cleaning fan, 2 speeds, 1200 and 1500 rpm, controlled by fan shutter
Force air-cleaning fan, 2 speeds, 1200 and 1500 rpm, controlled by fan shutter
Cleaning Area
2.5 Sq m.
Threshing Rotor Speed
600 RPM
500-1282 RPM
Rotor Speed Adjustment
Pulley Change
Pulley Change
Tyre Size
Front
14.9-28
Rear
7.5-16
Track assembly
Track Type
Full rubber/Bridgestone tracks, suitable for wet lands
Straw walker
No. Of Straw Walker
4
Straw Walkers Length
3300 MM
Straw Walkers Width
196 MM
