New Holland 3600 TX Heritage Edition

This Tractor Model Has Discontinued
Brand New Holland Tractors
Series TX Series Tractors
No. Of Cylinders 3
HP Category 47 HP
Gear Box Constant Mesh
Brakes Oil Immersed Multi Disc Brakes


Key Specifications Of New Holland 3600 TX Heritage Edition

Tractor HP
Tractor HP
47 HP
Wheel Drive
Wheel Drive
2WD
Clutch
Clutch
Single / Double
Gear Box
Gear Box
Constant Mesh
Steering
Steering
Mechanical / Power Steering

About New Holland 3600 TX Heritage Edition

New Holland 3600 TX Heritage Edition price in India was between INR 6,75,000* and INR 7,10,000* (Ex-Showroom). The New Holland 3600 TX Heritage Edition was a 47 HP tractor. New Holland has discontinued this model and launched its upgraded variants, New Holland 3600 TX Super Heritage Edition and New Holland 3600 TX Super Heritage Edition 4WD, with improved engines and more advanced features.

What are the Key Features of the New Holland 3600 TX Heritage Edition?

Engine

New Holland 3600 TX Heritage Edition had a 3-cylinder engine with a capacity of 2700 cc and delivered a power output of 47 HP at 2250 RPM. It generated a maximum torque of 168 Nm. It came with an oil bath air filter.

Transmission

New Holland 3600 TX Heritage Edition came with the option of single or double clutch. It had a constant mesh gearbox with the option of 8 forward + 2 reverse gears and optional 8 forward + 8 reverse gears with Synchro Shuttle. The gear lever position was Side Shift.

Brakes & Steering

New Holland 3600 TX Heritage Edition was equipped with oil immersed multi disc brakes and came with mechanical / power steering options.

PTO & Hydraulics

New Holland 3600 TX Heritage Edition came with EPTRA PTO. Its hydraulic lifting capacity was 1800 kg. This tractor featured HP Hydraulic with Multi-sensing point and Lift O Matic. It also had a DRC Valve with an option of single and double auxiliary valve.

Tyres

The New Holland 3600 TX Heritage Edition came with 6.5 x 16 front tyres and 13.6 x 28 / 14.9 x 28 rear tyres.

Weight & Dimensions

The weight of the New Holland 3600 TX Heritage Edition was 2040 kg. The wheelbase of this model was 1955mm and ground clearance was 425 mm.

Warranty

The New Holland 3600 TX Heritage Edition came with a warranty of 6000 hours or 6 years, whichever came earlier.

Which Upgraded Variants of New Holland 3600 TX Heritage Edition are available in India?

New Holland 3600 TX Heritage Edition has been discontinued. It has been replaced by its upgraded variant New Holland 3600 TX Super Heritage Edition. They have improved engine, higher PTO HP and more advanced features.

What is the New Holland 3600 TX Heritage Edition Price in India?

New Holland 3600 TX Heritage Edition price in India was between INR 6,75,000* and INR 7,10,000* (Ex-Showroom).

What are the Alternatives for New Holland 3600 TX Heritage Edition on Tractorkarvan?

Finding the perfect tractor as per your budget and farm needs is not an easy task. Tractorkarvan has simplified the selection process by providing all the key information of a model on a single page. You do not need to worry if the New Holland 3600 TX Heritage Edition tractor is not available in the market. You can still purchase its upgraded variants from us.

Another alternative is to consider second-hand New Holland 3600 TX Heritage Edition tractors available on our platform. Take the help of our hassle-free used tractor loan facility to buy a used tractor at an attractive interest rate.

Read More

New Holland 3600 TX Heritage Edition Engine

No. Of Cylinders 3
HP Category 47 HP
Engine Type Simpsons, TIIIA SJ327
Engine Rated RPM 2250 RPM
Max Torque 168 Nm
Capacity 2700 CC
Air Filter Oil Bath with Pre Cleaner
Cooling System Liquid Cooled
Fuel Type Diesel

New Holland 3600 TX Heritage Edition Transmission

Clutch Single / Double
Gear Box Constant Mesh
Gear Speed 8 Forward + 2 Reverse / 8 Forward + 8 Reverse Synchro Shuttle
Gear Lever Position Side Shift
Forward Speed 3.00 to 33.24 km/h
Reverse Speed 3.68 to 10.88 km/h
Brakes Oil Immersed Multi Disc Brakes

New Holland 3600 TX Heritage Edition Steering

Type Mechanical / Power Steering

New Holland 3600 TX Heritage Edition Power Take Off

PTO Speed Eptra PTO – 7 speeds PTO

New Holland 3600 TX Heritage Edition Fuel Capacity

Capacity 46 Litres

New Holland 3600 TX Heritage Edition Hydraulics

Hydraulics Controls HP Hydraulic with Multi sensing Point, Lift O Matic, DRC Valve
Remote / Auxillary Valve Single / Double

New Holland 3600 TX Heritage Edition Tyre Size

Wheel Drive 2WD
Front 6.50 X 16

New Holland 3600 TX Heritage Edition Dimensions And Weight

Total Weight 2040 kg
Wheel Base 1955 mm
Overall Length 3470 mm
Overall Width 1720 mm
Ground Clearance 425 mm

New Holland 3600 TX Heritage Edition Electrical

Battery 75 Ah
Alternator 35 Amp

New Holland 3600 TX Heritage Edition Safety Features

Neutral Safety Switch Yes
ROPS Yes
Clutch Safety Lock Yes

New Holland 3600 TX Heritage Edition Other Information

Warranty 6 Year/ 6000 Hours
Instrument Cluster Digital
Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy, Drawbar, Hitch
Additional Features Mobile Charging Port, Fan Belt Guard

New Holland 3600 TX Heritage Edition Variants

There are 3 Variants of New Holland 3600 TX Heritage Edition available on Tractorkarvan with complete specification and prices.

TractorKarvan Take On New Holland 3600 TX Heritage Edition

Good Things
  • Multi-sensing point and Lift O Matic.
  • Suitable for heavy-duty tasks.
  • Powerful lifting capacity in this HP range.
Could be Better
  • Oil bath air filter could have been replaced with dry type air filter.

New Holland 3600 TX Heritage Edition Verdict

New Holland 3600 TX Heritage Edition was made to carry legacy of Old Ford 3600 and comes with advanced features like shuttle shift, more gear speed, EPTRA PTO but NH upgraded this tractor with super series with all new FPT engine, 20 speed gearbox and more tyre size options.

Product review by TractorKarvan

4.6
overall
5
Power & Performance
4
Transmission
5
PTO & Hydraulics
5
Design & Styling
4
Ergonomics
