Brand Swaraj Tractors
Series XM Series Tractors
No. Of Cylinders 3
HP Category 30 - 35 HP
PTO HP 28.8
Brakes Dry Disc Type Brakes / Oil Immersed Disc Brakes (Optional)

Key Specifications of Swaraj 834 XM

Tractor HP
Tractor HP
30 - 35 HP
Wheel Drive
Wheel Drive
Single, Dry Disc Friction Plate
Mechanical Steering with Heavy Duty single drop arm
Lifting capacity
Lifting capacity

About Swaraj 834 XM

Swaraj 834 XM price in India ranges from INR 5.36 lakhs* to INR 5.64 lakhs*. Swaraj 834 XM HP is between 30 and 35, which is generated at an engine RPM of 1800.

The Swaraj 834 tractor has been manufactured as an environment-friendly, diesel-saving tractor following Bharat Trem III A standards. Swaraj 834 XM belongs to the tractor under 40 HP category.

Furthermore, the Swaraj 834 XM price is reasonable as it is a tractor under 7 lakhs category, making it the most preferred choice of Indian farmers. Belonging to the Swaraj XM series, they come under the category of lightweight tractors but are also very sturdy.

Keep reading to learn more about the Swaraj tractor 834 XM price, Swaraj 834 XM HP, key features, specifications, benefits, etc.

Swaraj 834 XM Tractor Top Specifications

Engine & Performance

  • Swaraj 834 HP range lies between 30-35 HP. The engine-rated speed is 1800 RPM. This model has an engine capacity of 2592 cc. The given configuration enables the tractor to complete heavy-duty tasks with fuel efficiency.
  • A liquid-cooling and a 3-stage oil bath air cleaning system enhance the engine life. The cooling system uses a coolant to prevent engine’s overheating.


  • The clutch type is a standard single dry disc friction plate. As a single clutch is simple in design, farmers can maintain/repair it with ease.
  • The gear system of the tractor includes 8 forward and 2 reverse gears. It allows the operator to find the ideal speed as per the requirement of a particular farm operation.

Power Take-Off (PTO)

  • Swaraj 834 XM has a PTO HP of 28.8. This available power is suitable for running a range of Swaraj implements.
  • Also, it offers the power to operate relatively bigger implements like RotavatorRotary Slasher, and Fertiliser Broadcaster.
  • It has a PTO speed of 1000 RPM, and 540 RPM is optional. The PTO speed of 1000 RPM is generated at an engine speed of 1650 ERPM. As a result, Swaraj 834 XM mileage is excellent.
  • Also, more PTO speed options allow the tractor to be compatible with more tractor implements.


  • Swaraj 834 XM lifting capacity is 1000 kg. Due to this lift capacity, it can support implements like the Tractor Trailer and Hydraulic Reversible MB Plough.
  • It is equipped with automatic depth and draft control type hydraulics with Category I & II 3-point linkage. Its ADDC system functions to control the implement depth as per the ground conditions.

Brakes & Steering

  • The Swaraj 834 XM tractor has an option for dry disc type and oil-immersed multi-disk brakes that prevent slippage. You can opt for an oil-immersed brake variant for better braking performance on slopes and under heavy loads.
  • It has standard mechanical steering (with a heavy-duty single drop arm). This steering is easy to maintain and thus can operate for several years.

Weight & Dimensions

  • Swaraj 834 XM weight is 1845 kg and has a wheelbase of 1930 mm. These two features ensure that the tractor remains stable even on uneven terrains.
  • This tractor's overall length and width are 3475 mm and 1705 mm, respectively. It possesses a ground clearance of 380 mm, ensuring that the tractor can easily operate in inter-row cultivation without damaging the crops.

Wheel Drive & Tyres

  • It is a 2WD (wheel drive) tractor. Thus, Swaraj 834 XM is lighter than 4WD models and easier to operate.
  • The tractor has front tyres and rear tyres with dimensions 6 X 16 and 12.4 X 28 / 13.6 X 28, respectively. These tractor tyres allow better grip on and off the field.

Swaraj 834 XM Tractor Unique Benefits

  • This model comes with a neutral safety switch. So, it can only start in neutral gear.
  • It has a deluxe driver seat with better suspension. Thus, it ensures comfort during long working hours.
  • Its additional features include a mobile charger, tap-off connection and steering lock.

Swaraj 834 XM Warranty

Swaraj 834 XM comes with a warranty of 2 years from purchase or 2000 hours of operation, whichever is earlier.

Swaraj 834 XM Price 2024 in India

Swaraj 834 XM price in India is reasonable, ranging from INR 5.36 lakhs* to INR 5.64 lakhs*, and its monthly EMI starts at INR 15,183 on Tractorkarvan. It is one of the most preferred tractors by farmers due to its efficiency and affordable Swaraj 834 XM price. Please note that the price shown here is the final Swaraj tractor 834 XM on road price.

However, if a farmer is thinking of purchasing accessories with this tractor, in that case, the final Swaraj tractor 834 XM on road price will vary since the accessories price is not included in the final price.

Also, you can use the compare tractors feature of Tractorkarvan to compare the Swaraj 834 XM with its counterparts like the Swaraj 735 FE and Swaraj 735 XT

Why choose Tractorkarvan for Swaraj 834 XM?

Tractorkarvan is a leading digital platform where you can find details about all the latest tractor models. We have a comprehensive list of Swaraj tractor dealers on the portal. As not all have the budget to buy a new tractor, you can explore our platform to buy a used Swaraj tractor or watch tractor videos to gain more information.

When you have selected your tractor, we ensure hassle-free tractor loan processing so that you can concentrate on elevating your business to great heights. Contact us today and learn more!

Read More

Swaraj 834 XM Engine

No. Of Cylinders 3
HP Category 30 - 35 HP
Engine Type RV-30 XM+ 3A, 4 Stroke, Direct Injection
Engine Rated RPM 1800 RPM
Capacity cc 2592 CC
Air Filter 3 Stage Oil Bath Type
Cooling System Liquid Cooled
Fuel Type Diesel
Bore / Stroke 100 / 110 mm
Emission Standard Bharat Trem III A

Swaraj 834 XM Transmission

Clutch Single, Dry Disc Friction Plate
Gear Speed 8 Forward + 2 Reverse
Gear Lever Position Centre Shift
Forward Speed 2.14 to 27.78 km/h
Reverse Speed 2.68 to 10.52 km/h
Brakes Dry Disc Type Brakes / Oil Immersed Disc Brakes (Optional)

Swaraj 834 XM Steering

Type Mechanical Steering with Heavy Duty single drop arm

Swaraj 834 XM Power Take Off

PTO HP 28.8 HP
PTO Speed 1000 RPM / 540 RPM (Optional)
RPM 1000 RPM @ 1650 ERPM

Swaraj 834 XM Hydraulics

Lifting capacity 1000 kg
3 Point Linkage CAT- I/II
Hydraulics Controls ADDC

Swaraj 834 XM Tyre Size

Wheel Drive 2WD
Front 6.00 X 16
Rear 12.4 X 28 / 13.6 X 28

Swaraj 834 XM Dimensions And Weight

Total Weight 1845 kg
Wheel Base 1930 mm
Overall Length 3475 mm
Overall Width 1705 mm
Ground Clearance 380 mm

Swaraj 834 XM Electrical

Battery 12 V, 88 Ah

Swaraj 834 XM Safety Features

Neutral Safety Switch Yes

Swaraj 834 XM Other Information

Warranty 2 Year/ 2000 Hours
Instrument Cluster Analog
Driver Seat Deluxe Driver Seat with Better Suspension
Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy, Drawbar, Hitch
Additional Features Steering Lock, Tap off Connection, Mobile Charger

TractorKarvan Take On Swaraj 834 XM

Good Things
  • Bigger Rear Tyre: Its big rear tyres provide better traction during farm operations.
  • Braking: OIB brakes offer better braking performance while offering longer life.
  • Diaphragm-Type Clutch: Offers more contact area and thus has a better life.
  • Safety: Prioritizes safety with features like a neutral safety switch and stabilizer bar to prevent movements of implements.
Could be Better
  • Centre shift gear is difficult to reach and can obstruct the operator's line of sight. A side shift gear is a better choice.

Swaraj 834 XM Verdict by TractorKarvan

There is no doubt that Swaraj 834 XM is a value-for-money model in its segment. It has been designed ergonomically to enhance the comfort of the operator while being balanced on every terrain. Another great thing about Swaraj 834 XM is its fuel-efficient engine. It is rare that a powerful engine offers top-notch efficiency. Its hydraulics and PTO system are capable enough to operate different types of attachments. Thus, if you are looking for a tractor that can improve farm productivity and is also low on maintenance costs, Swaraj 834 XM is among the top contenders.
