Brand ACE Tractors
No. Of Cylinders 4
HP Category 74.8 HP
Gear Box Synchromesh with Synchro Shuttle
Brakes Oil Immersed Multi Disc Brakes


Key Specifications of ACE DI 7500 4WD

Tractor HP
Tractor HP
74.8 HP
Wheel Drive
Wheel Drive
4WD
Clutch
Clutch
Double
Gear Box
Gear Box
Synchromesh with Synchro Shuttle
Steering
Steering
Power Steering
Lifting capacity
Lifting capacity
2200

About ACE DI 7500 4WD

ACE DI 7500 4WD price in India ranges from INR 12 lakhs* to INR 15 lakhs*. ACE DI 7500 4WD HP is 74.8 horsepower.

ACE, which stands for Action Construction Equipment Ltd, is an Indian material handling and equipment manufacturing company that was founded in 1995. ACE tractors are well-known for their rugged build quality and rigidness in the field. The tractors manufactured by ACE are widely used for agricultural, commercial, and construction purposes. Furthermore, these popular tractors are built to last on all-weather roads and have a low maintenance cost.

The company's manufacturing plant is in Faridabad, Haryana, and has an annual manufacturing capacity of 9000 tractors. ACE DI 7500 4WD is another powerful tractor made to accomplish challenging tasks easily. It is one of the top picks in the tractors above 70 HP category. Along with high power output, it is also very fuel efficient, which makes it a brilliant overall package. Let's discuss this tractor in detail in the below sections.

ACE DI 7500 4WD Top Specifications

Engine & Performance

  • ACE DI 7500 4WD HP is 74.8 horsepower. More power output allows the tractor to carry out heavy-duty farm operations quickly. Also, it helps to pull heavy and large tractor implements.
  • This tractor comes with 4 cylinders. The engine type provided in this 4WD tractor is A75 turbocharged diesel engine. A turbocharged engine can generate more power output compared to a same-sized naturally aspirated engine.
  • The engine-rated RPM is 2200. It allows the tractor to produce a greater power output so that it can handle challenging agricultural tasks. Also, this power is generated with optimal fuel consumption to lower operational costs.
  • The engine capacity is 4088 cc. With a bigger capacity, there is a larger engine volume to combust more fuel and produce greater power output.
  • This tractor can produce a maximum torque of 305 Nm. Due to high torque, this ACE model can work efficiently in challenging operating conditions like steep slopes. In addition, it helps pull heavy tractor attachments like Landscape Rake and Disc Plough.
  • This model has a dry air cleaner with a clogging sensor. It helps to keep the tractor engine free from impurities. It supplies filtered air to the engine for an efficient combustion process.
  • The liquid cooling system helps prevent engine overheating. This system dissipates the generated heat to sustain an ideal operating temperature, ensuring optimal engine performance for a long time.
  • The tractor's bore stroke ratio is 105/118 mm. With a longer stroke comes a larger engine displacement, which guarantees high torque at lower fuel consumption.

Transmission

  • This tractor features a double clutch. The main benefit of this clutch is that it provides seamless and quicker gear shifting. There is an independent clutch lever that makes operating attached implements convenient.
  • The transmission system of this tractor features a synchromesh gearbox with a synchro shuttle. Thus, gear shifting is easier as it has synchronisers that match the speed of gears before engaging them.
  • The tractor's gear speeds include 12 Forward + 12 Reverse gears. More gear speeds provide the flexibility to adapt to changing farm operations and working conditions. You can easily choose a suitable gear ratio to deliver efficient transmission with optimal fuel consumption. The tractor can attain a maximum forward speed of 31.25 km/h.

Hydraulics

  • ACE DI 7500 4WD has a massive lifting capacity of 2200 kg. With high lifting capacity, this tractor can easily manage heavy loads and operate a variety of hydraulic implements, including a Disc Harrow and Baler.
  • The hydraulic controls are ADDC type. Automatic Depth & Draft Control automatically controls the depth and draft of attached implements for maximum productivity on the field. Its top benefits include field uniformity and uniform working depth. This valve offers this tractor to operate hydraulic implements efficiently.
  • This ACE tractor also comes with a dual remote/auxiliary valve. This valve offers the tractor capability to operate hydraulic implements efficiently.

Weight & Dimensions

  • ACE DI 7500 4WD tractor weight is 2841 kg. The tractor's weight provides enhanced traction in various operating conditions, allowing it to maintain stability even when handling heavy loads on rugged terrain.
  • The overall length and width of this ACE tractor are 3990 mm and 2010 mm, respectively. The ACE DI 7500 4WD tractor's optimal size enables it to effectively distribute the weight of the load it carries, ensuring proper balance and stability during operations.
  • It comes with a wheelbase of 2235 mm. The tractor's longer wheelbase provides a solid foundation for supporting its own weight as well as the cargo it carries. This robust base enhances stability and ensures efficient load management.
  • The ground clearance of this ACE tractor is 405 mm. This ground clearance allows it to operate smoothly in diverse field conditions. Its design prevents crop damage during inter-cultivation activities, ensuring efficient farming operations and preserving the quality of the crops.
  • It comes with a turning radius of 4.05 m with brakes. The tractor's shorter turning radius enhances its manoeuvrability, particularly in tight spaces. This makes it an ideal choice for small fields where precise turns and navigation are required.

Wheel Drive & Tyres

  • It is among the top ACE four-wheel drive tractors in the market. This is why it can easily perform tough operations like puddling in wetlands.
  • The size of the front tyres and the rear tyres in this tractor is 11.20 × 24 and 16.9 × 28, respectively. The big tractor tyres of the ACE DI 7500 4WD provide excellent traction, offering a suitable grip even in challenging working conditions.

ACE DI 7500 4WD Key Benefits

  • Fuel Tank Capacity: This tractor features a fuel tank capacity of 65 litres. The generous fuel tank capacity of the ACE DI 7500 4WD tractor allows for extended working hours, ensuring sustained farm productivity without the need for frequent refuelling.
  • Brakes: This ACE tractor features oil-immersed multi-disc brakes. These brakes are designed to be fully immersed in oil, ensuring effective lubrication and cooling. This design feature enhances braking performance and helps maintain optimal functionality even during prolonged and demanding use.
  • Steering: The steering type provided in this tractor is power steering. It offers ease of steering that helps move the tractor easily on uneven terrains.
  • Power Take-Off: The ACE DI 7500 4WD tractor has a PTO speed of 540 RPM / 540E. The economy PTO speed provides the optimal speed for power take-off (PTO) operations while maximising fuel efficiency. This 540E PTO speed is produced at a lower ERPM, reducing fuel consumption.

ACE DI 7500 4WD Price in India 2023

ACE DI 7500 4WD price in India ranges from INR 12 lakhs* to INR 15 lakhs*. The price belongs to the tractors above 9 lakhs category; however, its features justify the pricing. Farmers with a low budget can also buy this tractor by taking a tractor loan from Tractorkarvan. To know the updated price of this tractor, customers need to visit the nearest ACE tractor dealers or contact Tractorkarvan directly.

Moreover, they can also compare this tractor with the other ACE models in a similar HP range using the compare tractors tool on Tractorkarvan. It will help them choose the best tractor according to their requirements. The other models in the similar HP are ACE DI 7575 2WDACE DI 7500 2WD, etc.

Why choose Tractorkarvan for ACE DI 7500 4WD?

At Tractorkarvan, customers can compare different tractor models and find all tractor brands in a single place. On our website, we have specialised sections where the buyers can compare the specifications of various models before buying them. Moreover, you can also buy and sell second-hand ACE tractors on Tractorkarvan. Check out tractor videos on our platform for more information about tractor models.

Besides, you can visit the platform to get information on ACE implements and ACE harvesters.

Tractorkarvan is a famous name for providing tractor loans to farmers. Our experts make loan financing easy and quick for buyers. We help farmers avail easy EMI options on the tractors they buy. So, contact Tractorkarvan now to learn more about the loan procedure.

Read More

ACE DI 7500 4WD Engine

No. Of Cylinders 4
HP Category 74.8 HP
Engine Type A75, Turbocharged
Engine Rated RPM 2200 RPM
Max Torque 305 Nm
Capacity cc 4088 CC
Air Filter Dry Type with Clogging Sensor
Cooling System Liquid Cooled
Fuel Type Diesel
Bore / Stroke 105 / 118 mm

ACE DI 7500 4WD Transmission

Clutch Double
Gear Box Synchromesh with Synchro Shuttle
Gear Speed 12 Forward + 12 Reverse
Forward Speed 1.52 - 31.25 km/h
Brakes Oil Immersed Multi Disc Brakes

ACE DI 7500 4WD Steering

Type Power Steering

ACE DI 7500 4WD Power Take Off

PTO Speed 540 RPM / 540 ERPM

ACE DI 7500 4WD Fuel Capacity

Capacity 65 Litres

ACE DI 7500 4WD Hydraulics

Lifting capacity 2200 kg
Hydraulics Controls ADDC
Remote / Auxillary Valve Dual

ACE DI 7500 4WD Tyre Size

Wheel Drive 4WD
Front 11.2 X 24
Rear 16.9 X 28

ACE DI 7500 4WD Dimensions And Weight

Total Weight 2841 kg
Wheel Base 2235 mm
Overall Length 3990 mm
Overall Width 2010 mm
Ground Clearance 405 mm
Turning radius with brake 4.05 m

ACE DI 7500 4WD Other Information

Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy
Additional Features Aerodynamic Bonnet, Tipping Pipe, Mobile Charger

ACE DI 7500 4WD Variants

There are 1 Variants of ACE DI 7500 4WD available on Tractorkarvan with complete specification and prices.

TractorKarvan Take On ACE DI 7500 4WD

Good Things
  • Engine: Turbocharged engine with 4 cylinders to produce more power output and torque.
  • Feature-rich: Equipped with several additional features, like a mobile charger, tipping pipe and aerodynamic bonnet.
  • Tyres: Big tyres offer better traction and less slippage on all surfaces.
  • Torque: High torque to manage heavy loads and operations in rugged terrain.
Could be Better
  • Could have offered more PTO speeds to operate a wide variety of tractor implements.

ACE DI 7500 4WD Verdict by TractorKarvan

ACE DI 7500 4WD tractor combines high torque and horsepower to deliver efficient performance, enabling farmers to tackle a wide range of tasks. With a balance between price and performance, it is well-suited for small to medium-sized farms or operations with demanding tasks. The tractor's reliable after-sales service ensures prompt assistance, minimises downtime, and contributes to the maintenance of its performance and longevity. If you are seeking a durable and powerful tractor, the ACE DI 7500 4WD comes highly recommended.

Product review by TractorKarvan

4.7
overall
4.5
Power & Performance
5
Transmission
5
PTO & Hydraulics
4.5
Design & Styling
4.5
Ergonomics

ACE DI 7500 4WD User Reviews

rating star icon 5/5
overall
Based on 9 Reviews
5
Performance
5
Comfort
4.9
Value for Money
4.9
Style & Looks

All Reviews

rating rating rating rating rating
Bhaar uthane ki chamta baki tractors ke muqable kam hai
Mai ACE ka tractor saal 2019 se istmaal kar raha jiska engine 74 hp ki power deta hai. Isme company ne saare features bahut hi shandaar diye hai. Halanki iski bhaar uthane ki chamta baki tractors ke muqable kam hai. Mere hisab se is tractor ko 5 me se 4.5 star milne chahiye.
2 months ago | Durga Shankar Gayari
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 4/5
Value for Money
rating star icon 4/5
Style & Looks
Read More
rating rating rating rating rating
Kaise bhi raste me ye tractor chal skta hai
Bina doubt ke ye ek bahut hi heavyduty tractor hai. isse bade kaam asaani se kiye ja sakte hai. iska sabsa bada reason hai tractor me four wheel drive hone. isse kaise bhi raste me ye tractor chal sakta hai aur kahi bhi kheti kar sakta hai bina balance khoye
2 months ago | Jagdish Vaijanath Biradar
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 5/5
Style & Looks
Read More
rating rating rating rating rating
Koyi bhi kaam me solid performance deta hai
Iski body bahut tough banayi gayi hai. isse kheti ya koyi bhi kaam karte time ye tractor solid performance deta hai. majboot parts hone se ye tractor lamba bhi chalega. isko chalane bhi asaan hai naye driver ko bhi dikkat nahi hogi. power steering aur bhi kaam ko asaan kar deta hai
2 months ago | Jagdish Vaijanath Biradar
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 5/5
Style & Looks
Read More
rating rating rating rating rating
Is keemat me itne features koyi nahi deta
Is keemat me ye tractor sabse acchhi deal hai. itne features koyi aur nahi deta. diesel bhi kam peeta hai jisse aur paise ki bachat hoti hai. ye paise mai achhi quality ke seeds aur khaad lene me use kar leta hu. isse fasal ki quality bhi achhi rehti hai
2 months ago | Manik Hari Rathod
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 5/5
Style & Looks
Read More

Suitable Tyres


ACE Tractor Dealers & Service Centers

Frequently Asked Questions on ACE DI 7500 4WD

1. What is the price of ACE DI 7500 4WD in India 2023?

The ACE DI 7500 4WD price in India 2023 ranges from INR 12 lakhs* to 15 lakhs*.

The HP of ACE DI 7500 4WD is 74.8 horsepower.

The wheelbase of ACE DI 7500 4WD is 2235 mm.

The fuel tank capacity of ACE DI 7500 4WD is 65 litres.

Yes, you may purchase the ACE DI 7500 4WD tractor on EMI.

ACE DI 7500 4WD has a lifting capacity of 2200 kg.

The total weight of the ACE DI 7500 4WD tractor is 2841 kg.
