Brand ACE Tractors
No. Of Cylinders 4
HP Category 88.4 HP
Gear Box Synchromesh with Synchro Shuttle
Brakes Oil Immersed Multi Disc brakes


Key Specifications Of ACE DI 9000 4WD

Tractor HP
Tractor HP
88.4 HP
Wheel Drive
Wheel Drive
4WD
Clutch
Clutch
Double
Gear Box
Gear Box
Synchromesh with Synchro Shuttle
Steering
Steering
Power Steering
Lifting capacity
Lifting capacity
2500

About ACE DI 9000 4WD

ACE DI 9000 4WD price in India ranges from INR 15 lakhs* to INR 18 lakhs*. ACE DI 9000 4WD HP is 88.4 horsepower.

ACE Limited is the manufacturer of ACE tractors. The brand has been the recipient of numerous awards and recognitions ever since its beginning in 1995. The company specialises in the production of agricultural machinery. The company was also named the best brand in 2018. ACE products have a notable reputation all around the world, though they are manufactured only in India. The company produces 9000 tractors annually, out of which we are going to discuss one of the best in the tractors above 70 HP category.

ACE DI 9000 4WD is one of the outstanding and most powerful 4WD tractors from the company. It is a popular tractor with all the facilities to fulfil modern farming needs. We have listed below in detail the complete information and specifications of the ACE DI 9000 4WD tractor.

ACE DI 9000 4WD Top Specifications

Engine & Performance

  • ACE DI 9000 4WD HP is 88.4 horsepower, making it one of the most powerful tractor models in India. It means this model can easily manage more demanding and larger farm tasks like operating larger tractor implements and pulling heavier loads.
  • It has 4 cylinders. The engine type of this tractor is A90 turbocharged with an intercooler. A turbocharged engine produces more power output compared to a naturally aspirated engine of a similar size.
  • Its engine-rated RPM is 2200. This ERPM is within an ideal range that not only produces higher power output but also ensures greater fuel consumption.
  • The maximum torque generated by this tractor is 305 Nm. With this high torque output, the tractor can easily handle heavy loads and operations in challenging working conditions. Besides, it can pull heavy implements like Ripper and Subsoiler.
  • The company has provided a 4088-cc engine in this tractor. A larger engine volume allows the combustion of more amount of fuel to produce greater power output.
  • The presence of a dry air cleaner with a clogging sensor. This air cleaner ensures that the air that is supplied to the combustion chamber is free of dust and other impurities that can damage engine components.
  • It has a liquid cooling system to maintain the engine’s operating temperature. Extreme heat is generated during operations, which needs to be dissipated to optimise engine performance and lifespan.
  • The tractor’s bore stroke ratio is 105/118 mm. The engine displacement is larger because of the longer stroke. It delivers more torque output while consuming less amount of fuel.

Transmission

  • ACE DI 9000 4WD comes with a double clutch option. The primary benefit of this clutch is smoother shifting than a single clutch. In addition, it comes with an independent clutch hand lever for power take-off, ensuring seamless operation of tractor implements.
  • The transmission system of this ACE tractor includes a synchromesh gearbox with a synchro shuttle. Synchronisers match the speed of gears before engaging, resulting in easy and quick gear shifting.
  • The tractor also features 12 Forward + 12 Reverse gear speeds. These many gear speeds offer a wide range of gear ratios for adapting to different tasks and operating conditions. So, you can conveniently conduct both high-speed transportation and slow-speed operations. Also, it offers a forward speed range of 1.70 to 35.08 km/h.

Hydraulics

  • The maximum hydraulic lifting capacity of this ACE tractor is 2500 kg. Heavy loads can be easily handled using such a high lifting capacity. Also, it allows the efficient operation of a range of heavy hydraulic implements, including Disc Harrow and Baler.
  • The tractor has an ADDC (automatic draft and depth control) hydraulic system. This system allows the tractor to automatically adjust the position of attachments to enhance their productivity. The key benefits of ADDC include field uniformity and consistent working depth.
  • The tractor also features a dual remote/auxiliary valve. This valve plays a huge role in allowing the working of hydraulic implements effectively.

Brakes & Steering

  • This ACE tractor is equipped with oil-immersed multi-disc brakes that experience lesser brake fade. The braking system has oil for constant lubrication that enhances the braking performance.
  • The steering type of this tractor is power steering. It helps to manoeuvre the tractor without putting in much steering effort, making long hours on the field comfortable.

Weight & Dimensions

  • ACE DI 9000 4WD has a total weight of 2976 kg. The tractor gets improved traction due to this weight. It stabilises the tractor when operating in rugged terrain.
  • The wheelbase of this ACE tractor is noted to be 2235 mm. With a longer wheelbase, the tractor gets a good base of support to handle heavy workloads, enhancing the stability of the tractor.
  • Its overall length and width are 4020 mm and 2040 mm, respectively. The perfect size of this tractor is due to these dimensions, which also ensure proper weight distribution.
  • The ground clearance of this tractor is noted to be 420 mm. High ground clearance permits operations in varying field conditions easier, including uneven terrain. Also, there is no damage to crops during inter-cultivation operations.
  • This ACE model has a 4 m turning radius with brakes. It makes navigation in small fields and tight spaces convenient.

Wheel Drive & Tyres

  • This model is among the best ACE four-wheel drive tractors. Thus, it can swiftly complete challenging tasks in tough operating conditions like wetlands.
  • The front tyre size of this tractor is 12.4 X 24, and the rear tyre size is 18.4 X 30. With big tractor tyres, the tractor gets better traction or grip even on rugged terrains.

ACE DI 9000 4WD Key Benefits

There are many benefits of this ACE tractor which makes it an ideal choice for farm use. Some advantages of this tractor are:

  • Clutch: This tractor has a double clutch system, which offers easier and seamless gear changes. One of the clutches is used for the PTO (power take-off) speed which is 540 RPM/540E, and the other (the primary one) is used for travel speed.
  • Air Filter: It consists of a dry air cleaner that leaves no debris or impurities. Since it is a dry air filter, there is a clogging detector to alert you whenever the filter needs cleaning so that you can avoid unwanted clogs in the filter.
  • Gearbox: The gearbox has a synchromesh gear. This type of gearbox is just an advanced version of the constant mesh gear. It has a longer lifespan as its gears experience lesser wear and tear.
  • Power Take-Off: The PTO speed of this ACE tractor is 540 RPM / 540E. With economy 540E PTO speed, you get the standard PTO speed at a lower engine-rated speed. It means the fuel consumption is lower, reducing operational costs for you.
  • Fuel Capacity: It runs on diesel and has a fuel tank capacity of about 65 litres. Such a big tank allows extended operations to do more work on the field. The mileage of the tractor is better than its predecessors as it is the latest model in the series.

ACE DI 9000 4WD Price in India 2023

The ACE DI 9000 4WD price in India ranges between INR 15 lakhs* to INR 18 lakhs*. The price of the tractor differs slightly depending on the city and state. If you want to know the updated on-road price of this tractor model, then visit your nearest ACE tractor dealer or contact Tractorkarvan.

Here, you may also compare two models using the compare tractors tool before making your purchase. The other models in the similar HP range are ACE DI 7500 4WDACE DI 7575 2WD, etc.

Why choose Tractorkarvan for ACE DI 9000 4WD?

Tractorkarvan is one of the best online portals to get information about new and second-hand ACE tractors. The portal also makes it easy to get a loan if you need one, making it simpler to launch a successful farming venture. We have a wide range of the latest tractors for your inspection. You can go through tractor videos on Tractorkarvan to gain a better understanding of tractors. In addition to tractors, we also sell a wide selection of tractor attachments. So, if you need any information regarding a tractor or ACE implements, contact Tractorkarvan now!

Read More

ACE DI 9000 4WD Engine

No. Of Cylinders 4
HP Category 88.4 HP
Engine Type Turbocharged with Intercooler
Engine Rated RPM 2200 RPM
Max Torque 305 Nm
Capacity 4088 CC
Air Filter Dry Type with Clogging Sensor
Cooling System Liquid Cooled
Fuel Type Diesel
Bore / Stroke 105 / 118 mm

ACE DI 9000 4WD Transmission

Clutch Double
Gear Box Synchromesh with Synchro Shuttle
Gear Speed 12 Forward + 12 Reverse
Forward Speed 1.70 - 35.08 km/h
Brakes Oil Immersed Multi Disc brakes

ACE DI 9000 4WD Steering

Type Power Steering

ACE DI 9000 4WD Power Take Off

PTO Speed 540 RPM / 540 ERPM

ACE DI 9000 4WD Fuel Capacity

Capacity 65 Litres

ACE DI 9000 4WD Hydraulics

Lifting capacity 2500 kg
Hydraulics Controls ADDC
Remote / Auxillary Valve Dual

ACE DI 9000 4WD Tyre Size

Wheel Drive 4WD
Front 12.4 X 24
Rear 18.4 X 30

ACE DI 9000 4WD Dimensions And Weight

Total Weight 2976 kg
Wheel Base 2235 mm
Overall Length 4020 mm
Overall Width 2040 mm
Ground Clearance 425 mm
Turning radius with brake 4 m

ACE DI 9000 4WD Other Information

Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy
Additional Features Aerodynamic Bonnet, Tipping Pipe, Mobile Charger

TractorKarvan Take On ACE DI 9000 4WD

Good Things
  • Feature-rich: Offers several additional features, including a mobile charger and aerodynamic bonnet.
  • Engine: Offers high torque to handle heavy workloads with lower fuel consumption.
  • Tyres: Big tractor tyres for excellent grip on all kinds of terrains.
  • ADDC: Allow efficient and productive operation of a wide range of implements.
Could be Better
  • Could have featured more PTO speed options for operating a variety of implements.

ACE DI 9000 4WD Verdict

ACE DI 9000 4WD comes with a powerful engine that significantly enhances its versatility and expands its range of applications. This robust engine enables the tractor to handle a wide variety of tasks and work effectively with various implements. Whether it is ploughing, seeding, or hauling, this model can perform efficiently in diverse farming operations. The 4WD system of this tractor plays a vital role in improving traction and stability, especially in challenging working conditions. By considering ACE DI 9000 4WD, farmers gain access to a dependable and versatile tractor that can manage a variety of tasks and adapt to different operational requirements.

Product review by TractorKarvan

4.6
overall
4.5
Power & Performance
4.5
Transmission
4.5
PTO & Hydraulics
5
Design & Styling
4.5
Ergonomics

ACE DI 9000 4WD User Reviews

No Reviews found. Be the first one to review!


Similar Used Tractors

ACE DI 450 NG Second Hand Tractor
DI 450 NG
ACE
2019 | Price ₹4.00 Lakh
Bijnor, Uttar Pradesh
Get More Details
ACE DI 350 Star Second Hand Tractor
DI 350 Star
ACE
2011 | Price ₹2.00 Lakh
Chitrakoot, Uttar Pradesh
Get More Details

Similar Brands


Similar To ACE DI 9000 4WD

Indo Farm 4190 DI Tractor
4190 DI
Indo Farm
90 HP 2WD
Get More Details
Same Deutz Fahr Agrolux 75 Profiline Tractor
Agrolux 75 Profiline
Same Deutz Fahr
75 HP 2WD
Get More Details
New Holland Workmaster 105 Tractor
Workmaster 105
New Holland
106 HP 4WD
Get More Details
Solis S90 4WD Tractor
S90 4WD
Solis
90 HP 4WD
Get More Details

Suitable Implements

Lancer Maximo 205 Rotavator Implement
Maximo 205
Lancer
7 Feet Rotavator
60-100 HP

Get More Details
Sonalika Offset Mounted 8X8 Disc Harrow Implement
Offset Mounted 8X8
Sonalika
Disc Harrow
50+ HP

Get More Details
Maschio Gaspardo Chiara 180 Shredder Implement
Chiara 180
Maschio Gaspardo
Shredder
50-90 HP

Get More Details
Fieldking Heavy Duty Hydraulic FKHDHH 26-22 Disc Harrow Implement
Heavy Duty Hydraulic FKHDHH 26-22
Fieldking
Disc Harrow
90-110 HP

Get More Details

Suitable Tyres

7

Yrs
Certified
JK Sona-1 Tractor Front (Bias) 12.4-24 Tyre
Sona-1 Tractor Front (Bias) 12.4-24
JK Tyres
Front TyreSize - 12.40 X 24
Get More Details
BKT 18.4-30 Commander 8 PR (R) Tyre
18.4-30 Commander 8 PR (R)
BKT Tyres
Rear TyreSize - 18.40 X 30
Get More Details
BKT 18.4-30 COMMANDER 14 PR (R) Tyre
18.4-30 Commander 14 PR (R)
BKT Tyres
Rear TyreSize - 18.40 X 30
Get More Details
MRF 12.4-24 SHAKTI LIFE - TT (F) Tyre
12.4-24 Shakti Life - TT (F)
MRF Tyres
Front TyreSize - 12.40 X 24
Get More Details

ACE Tractor Dealers & Service Centers

Opp Kerekodi, Pandavapura Main Road, Pandavapura, Mandya, Karnataka - 571434
+91-*******356
Contact Dealer

Frequently Asked Questions On ACE DI 9000 4WD

1. What is the engine power of ACE DI 9000 4WD?

The engine power of ACE DI 9000 4WD is 88.4 HP.

The fuel tank capacity of ACE DI 9000 4WD is 65 litres.

The lifting capacity of ACE DI 9000 4WD is 2500 kg.

ACE DI 9000 4WD has a wheelbase of 2235 mm.

The weight of ACE DI 9000 4WD is 2976 kg.

The ACE DI 9000 4WD price in India 2024 ranges from INR 15 lakhs* to INR 18 lakhs*.
