Brand ACE Tractors
No. Of Cylinders 4
HP Category 88.4 HP
Gear Box Synchromesh with Synchro Shuttle
Brakes Oil Immersed Multi Disc brakes


Key Specifications Of ACE DI 9000 4WD

Tractor HP
Tractor HP
88.4 HP
Wheel Drive
Wheel Drive
4WD
Clutch
Clutch
Double
Gear Box
Gear Box
Synchromesh with Synchro Shuttle
Steering
Steering
Power Steering
Lifting Capacity
Lifting Capacity
2500

About ACE DI 9000 4WD

ACE DI 9000 4WD price in India starts at INR 15,60,000* and goes up to INR 15,75,000* (Ex-Showroom). ACE DI 9000 4WD is a 88.4HP four-wheel drive tractor.

What are the Key Features of ACE DI 9000 4WD Tractor?

Engine & Transmission

  • The 4-cylinder, liquid cooled, turbocharged engine of ACE DI 9000 4WD tractor generates a power of 88.4HP at 2200 RPM.
  • It has an engine capacity of 4088 cc, bore-to-stroke ratio of 105/188 and maximum torque of 355.
  • The transmission system of ACE DI 9000 4WD consists of synchro shuttle gearbox, double clutch and a gear speed option of 12 forward and 12 reverse gears.

PTO & Hydraulics

  • The mechanically actuated, hand-operated PTO has a PTO speed of 540 RPM / 540 E RPM.
  • The ADDC hydraulics system comes with a maximum lifting capacity of 2500 kg and dual remote/ auxillary valve.

Brakes & Steering

  • It has mechanically actuated oil-immersed disc brakes and power steering to control the tractor.

Tyre Size

  • The front and rear tyres of ACE DI 9000 4WD tractor measure 12.4 X 24 and 18.4 X 30, respectively.

Dimensions & Fuel Capacity

  • The overall weight of ACE DI 9000 4WD tractor is 2976 kg.
  • The wheelbase of this tractor is 2235 mm long.
  • The ground clearance is 420 mm and turning radius with brakes is 4 meters.
  • The fuel tank capacity of this ACE 4WD tractor is 65 litres.

Rivals

What is the ACE DI 9000 4WD Price in 2025?

The ACE DI 9000 4WD price in India 2025 is in the range of INR 15,60,000* to INR 15,75,000* (Ex-Showroom). The on-road price of this tractor is usually higher than the ex-showroom price and differs across states due to inclusion of RTO fees, insurance cost, etc.

Why Prefer to Buy ACE DI 9000 4WD at Tractorkarvan?

We are a leading online platform to view new tractors such as ACE DI 9000 4WD. Here, you can get all the information, such as price and specifications, related to ACE tractors. Besides, you can also compare this tractor with other tractors using compare tractors feature on the portal. You can also view this tractor on easy EMIs by applying for a tractor loan on the website.

In addition to above, you can explore Tractorkarvan to get information on 4WD tractors from other brands.

Read More

ACE DI 9000 4WD Engine

No. Of Cylinders 4
HP Category 88.4 HP
Engine Type Turbocharged with Intercooler
Engine Rated RPM 2200 RPM
Max Torque 305 Nm
Capacity 4088 CC
Air Filter Dry Type with Clogging Sensor
Cooling System Liquid Cooled
Fuel Type Diesel
Bore / Stroke 105 / 118 mm

ACE DI 9000 4WD Transmission

Clutch Double
Gear Box Synchromesh with Synchro Shuttle
Gear Speed 12 Forward + 12 Reverse
Forward Speed 1.70 - 35.08 km/h
Brakes Oil Immersed Multi Disc brakes

ACE DI 9000 4WD Steering

Type Power Steering

ACE DI 9000 4WD Power Take Off

PTO Speed 540 RPM / 540 ERPM

ACE DI 9000 4WD Fuel Capacity

Capacity 65 Litres

ACE DI 9000 4WD Hydraulics

Lifting Capacity 2500 kg
Hydraulics Controls ADDC
Remote / Auxillary Valve Dual

ACE DI 9000 4WD Tyre Size

Wheel Drive 4WD
Front 12.4 X 24
Rear 18.4 X 30

ACE DI 9000 4WD Dimensions And Weight

Total Weight 2976 kg
Wheel Base 2235 mm
Overall Length 4020 mm
Overall Width 2040 mm
Ground Clearance 420 mm
Turning radius with brake 4 m

ACE DI 9000 4WD Other Information

Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy
Additional Features Aerodynamic Bonnet, Tipping Pipe, Mobile Charger

TractorKarvan Take On ACE DI 9000 4WD

Good Things
  • 4-cylinder powerful and heavy-duty engine.
  • High torque and best pulling power.
  • Longest wheelbase in the 90 HP segment.
  • 4 auxiliary valves for hydraulic implements.
Could be Better
  • More PTO speeds could have been provided.

ACE DI 9000 4WD Verdict

ACE DI 9000 4WD with its 90 HP engine is a powerful tractor for every farm task. Its aerodynamic bonnet gives it a bold & stylish look and its big driving seat ensures that you can work for longer hours. Besides, longer wheelbase along with front weight carrier ensures excellent stability on any terrain. Overall, it’s a big tractor to handle bigger agricultural tasks.

Product review by TractorKarvan

4.6
Overall
4.5
Power & Performance
4.5
Transmission
4.5
PTO & Hydraulics
5
Design & Styling
4.5
Ergonomics

ACE DI 9000 4WD User Reviews

rating star icon 5/5
Overall
Based on 1 Reviews

All Reviews

Sort By:
Latest
  • Latest
  • Ratings 5 to 1
  • Ratings 1 to 5
rating rating rating rating rating
इस ट्रैक्टर में ड्यूल क्लच और एक ऑप्टिमल गियर सिस्टम है, जो कृषि कामों को बहुत आसान बनाता है। भारी लोड उठाने के लिए इसका हाइड्रोलिक सिस्टम बहुत अच्छा है और इससे खेती के सभी काम, जैसे हल चलाना और पानी देना, जल्दी हो जाते हैं।
8 months ago | Sunny Y
Read More

Similar Brands


Similar To ACE DI 9000 4WD

New Holland Workmaster 105 Tractor
Workmaster 105
New Holland
106 HP 4WD
Get More Details
Same Deutz Fahr Agrolux 75 Profiline Tractor
Agrolux 75 Profiline
Same Deutz Fahr
75 HP 2WD
Get More Details
Indo Farm 3090 DI 4WD Tractor
3090 DI 4WD
Indo Farm
90 HP 4WD
Get More Details
Indo Farm 4195 DI 4WD Tractor
4195 DI 4WD
Indo Farm
95 HP 4WD
Get More Details

Suitable Implements

VST Shakti FT 20 Power Weeder Implement
FT 20
VST Shakti
Power Weeder
1.8 HP

Get More Details
Balwan BW-25 Power Weeder Implement
BW-25
Balwan
Power Weeder
3 HP

Get More Details
VST Shakti FT 35 GE Power Weeder Implement
FT 35 GE
VST Shakti
Power Weeder
3.5 HP
Price starts ₹43,500
Get More Details
Gomadhi WBT-4R Rice Transplanter Implement
WBT-4R
Gomadhi
Rice Transplanter
4 HP

Get More Details

Suitable Tyres

7

Yrs
Certified
JK Sona-1 Tractor Front (Bias) 12.4-24 Tyres
Sona-1 Tractor Front (Bias) 12.4-24
JK Tyres
Front TyresSize - 12.40 X 24
Get More Details
MRF 12.4-24 SHAKTI LIFE - TT (F) Tyres
12.4-24 Shakti Life - TT (F)
MRF Tyres
Front TyresSize - 12.40 X 24
Get More Details
MRF 12.4-24 KRISHI - TT Tyres
12.4-24 Krishi - TT
MRF Tyres
Rear TyresSize - 12.40 X 24
Get More Details
BKT 12.4-24 Commander 12 PR (R) Tyres
12.4-24 Commander 12 PR (R)
BKT Tyres
Rear TyresSize - 12.40 X 24
Get More Details

ACE Tractor Dealers & Service Centers

Opp Kerekodi, Pandavapura Main Road, Pandavapura, Mandya, Karnataka - 571434
+91-*******356
Contact Dealer

ACE Tractor Blogs

Frequently Asked Questions On ACE DI 9000 4WD

1. What is the price range of ACE DI 9000 4WD tractor in India?

The ACE DI 9000 4WD tractor comes in the price range of INR 15,60,000* - 15,75,000* (Ex-Showroom).

ACE DI 9000 4WD is an 88.4 HP tractor.

The overall weight of the ACE DI 9000 4WD tractor is 2976 kg.

ACE DI 9000 4WD tractors comes with 24 gear speeds option in 12F + 12R pattern.

Preet 9049 4WD and Solis S90 4WD are some of the alternatives to ACE DI 9000 4WD tractor.
