Brand New Holland Tractors
Series TX Series Tractors
No. Of Cylinder 3
HP Category HP range 44
PTO HP 38
Gear Box Constant Mesh
Brakes Oil Immersed Multi Disc Brakes


Key Specifications of New Holland 3230 TX

Tractor HP
Tractor HP
44 HP
Wheel Drive
Wheel Drive
2WD
Clutch
Clutch
Single / Double
Gear Box
Gear Box
Constant Mesh
Steering
Steering
Mechanical / Power Steering
Lifting capacity
Lifting capacity
1800 KG

About New Holland 3230 TX

New Holland 3230 TX price in India ranges from INR 6.75 lakhs* to INR 8.88 lakhs*. New Holland 3230 HP is observed to be 44 horsepower generated at an engine RPM of 2000. Its engine capacity is 2500 cc.

New Holland tractors are counted amongst the best tractors built for the convenience of Indian farmers and Indian soil conditions. Its latest tractor model is the New Holland 3230 TX from the New Holland TX Series.

The New Holland 3230 price is budget-friendly even though it belongs to the tractors under 50 HP category. Designed for new-age farmers who prefer modern technology integrations, it comes with a powerful engine and many other advanced features that make it a bestseller.

If you are looking for popular tractors, you need not think twice before buying New Holland 3230 TX. We have listed more details, key specifications and features below. You can also check the New Holland tractor 45 hp price list 2023.

New Holland 3230 TX Top Specifications

Engine & Performance

  • New Holland 3230 HP is 44 horsepower. Equipped with 3 cylinders, the engine generates higher power output at the maximum engine rates RPM of 2000. As a result, the tractor can easily perform heavy-duty farming tasks.
  • The New Holland 3230 TX engine capacity is 2500 cc. A larger engine displacement allows generation of more power output and torque output. Thus, its maximum torque is 160.7 Nm enabling it to pull implements like Disc Seed Drill and Zero Till.
  • The engine type is Simpsons, TIIIA S325, which is a Trem IIIA compatible engine resulting in less emission of pollutants while working on farm.
  • The engine consists of a liquid-cooled cooling system to prevent overheating of the engine.
  • The oil bath air filter with a pre-cleaner ensures that only clean air is supplied to the engine for internal combustion.

Transmission

  • New Holland 3230 comes with a fully constant mesh AFD gearbox. You get smoother and easier gear shifting with this gearbox, as all its gears are always engaged.
  • It comes in two clutch options, single or double. A double clutch permits the preselection of the next gear, which leads to fewer power flow interruptions. Thus, it offers smoother gear shifting than a single clutch.
  • The gear pattern includes the option of 8 Forward + 2 Reverse and 8 Forward + 8 Reverse Synchro Shuttle. These gear speeds allow selecting a suitable speed based on the requirement of the farm task or terrain.
  • The forward and reverse speed ranges between 2.50 to 30.81 km/h and 3.11 to 11.30 km/h, respectively.
  • It has a side shift gear lever. The operator can change gears conveniently as this gear lever can be easily accessed.

Power Take-Off

  • New Holland 3230 PTO HP is 38 horsepower; thus, the tractor is compatible with bigger PTO-driven implements, including Mulchers and Rotary Slasher.
  • This tractor model comes with Eptra PTO speed or 7 speeds PTO. Equipped with more PTO speeds, this model can work with various tractor implements that need different PTO speeds to run.

Hydraulics

  • New Holland 3230 lifting capacity is 1800 kg. You can operate a range of larger hydraulic implements with this model, like Disc Harrow and Hydraulic Reversible MB Plough.
  • It also comes equipped with an HP Hydraulic system with Multi sensing Point, a Lift O Matic, as well as a DRC Valve for simplifying heavy-duty farming operations.
  • It offers a choice between a single or a double remote/auxiliary valve. The hydraulic implements work seamlessly with this model using this valve.

Weight & Dimensions

  • New Holland 3230 weight is 1810 kg with a substantial wheelbase of 1920 mm. Its weight and wheelbase provide suitable stability to the tractor during operations in harsh conditions.
  • It is 3415 mm in length and 1700 mm in width. The weight of the tractor is ideally distributed with these dimensions.
  • With its ground clearance of 390 mm along with a 2.8 m turning radius, this tractor is safe to operate on any farmland. A less turning radius helps it to take sharp turns in tighter spaces.

Brakes & Steering

  • The tractor comes with oil-immersed multi-disc brakes for improved braking performance as they constantly have oil to lubricate them.
  • This tractor comes with two optional steering types; mechanical steering and power steering. Less steering effort is required in power steering, ensuring a comfortable ride experience. That is why the New Holland 3230 power steering price is higher than the mechanical steering variant.

Wheel Drive & Tyres

  • This model is a two-wheel-drive variant. Being a 2WD model, it has lower maintenance and simpler operation than 4WD models.
  • It comes with a front tyre size of 6.00 X 16 / 6.50 X 16 and a rear tyre size of 13.6 X 28. This model has a perfect grip on varying surface conditions due to these excellent tractor tyres.

New Holland 3230 TX Key Benefits

  • It has a big fuel tank capacity of 46 litres. It is enough for day-long operation; on the other hand, New Holland 3230 mileage is excellent.
  • It comes with a powerful 75 Ah battery along with a 35 Amp alternator that aids in the perfect operation of the electrical components of the tractor.
  • Designed for ultimate safety for its operators, this tractor comes with a built-in neutral safety switch, a differential lock, a ROPS, as well as a clutch safety lock.
  • New Holland 3230 tractor is compatible with accessories like Tools, ballast weight, bumper, canopy, top link, and hitch.
  • 3230 New Holland price offers other handy features of this tractor, like a digital instrument cluster, mobile charging port, drawbar, and a fan belt guard.
  • It also comes with a straight-axle planetary drive for the Rear Axle. The load on the rear axle gets distributed over three points. Thus, there is lesser stress on gears and shafts, ensuring longer life.

New Holland 3230 TX Warranty

New Holland 3230 TX comes with a warranty of 6000 hours or 6 years, whichever is earlier from the date of purchase.

New Holland 3230 Price 2023

The New Holland 3230 price is quite economical, as a result, the New Holland 3230 45 HP tractor price ranges from INR 6.75 lakhs* to INR 8.88 lakhs*. It is a tractors under 9 lakhs category. You can even buy this tractor on a tractor loan facility with a starting EMI of INR 14,979 per month.

The on road New Holland tractor 3230 price may vary depending on the states and their transport rules. You can check the prices the given New Holland tractor 45 HP price list on the portal.

You can use the compare tractor feature to compare the New Holland tractor 3230 price with other tractor models of this brand belonging to the same HP category. Such models include New Holland 3600-2 TX and New Holland Excel 4710 4WD.

Why choose Tractorkarvan for New Holland 3230 TX?

Tractorkarvan is known to be a trustworthy online platform that offers farmers a detailed catalogue of top tractors of all tractor brands. So, users searching for information on the New Holland 3230 45 HP price should prefer Tractorkarvan. It contains all the information regarding second-hand New Holland tractors and New Holland tractor dealers. So, contact Tractorkarvan now and grab the best deal on the 3230 New Holland price.

Read More

New Holland 3230 TX Engine

No. Of Cylinder 3
HP Category HP range 44
Engine Type Simpsons, TIIIA S325
Engine Rated RPM 2000 RPM
Max Torque 161 Nm
Capacity CC 2500 CC
Air Filter Oil Bath with Pre Cleaner
Cooling System Liquid Cooled
Fuel Type Diesel
Emission Standard Bharat Trem III A

New Holland 3230 TX Transmission

Clutch Single / Double
Gear Box Constant Mesh
Gear Speed 8 Forward + 2 Reverse / 8 Forward + 8 Reverse Synchro Shuttle
Forward Speed 2.50 to 30.81 KM/H
Reverse Speed 3.11 to 11.30 KM/H
Gear Lever Position Side Shift
Brakes Oil Immersed Multi Disc Brakes
Rear Axle Straight Axle Planetary Drive

New Holland 3230 TX Steering

Type Mechanical / Power Steering

New Holland 3230 TX Power Take Off

PTO HP 38 HP
PTO Speed Eptra PTO – 7 speeds PTO

New Holland 3230 TX Fuel Capacity

Capacity 46 Litres

New Holland 3230 TX Hydraulics

Lifting Capacity 1800 KG
Hydraulic Controls HP Hydraulic with Multi sensing Point, Lift O Matic
Remote / Auxillary Valve Single / Dual (Optional)

New Holland 3230 TX Tyre Size

Wheel Drive 2WD
Front 6.00 X 16 / 6.50 X 16
Rear 13.6 X 28

New Holland 3230 TX Dimensions And Weight

Total Weight 1810 kg
Wheel Base 1920 mm
Overall Length 3415 mm
Overall Width 1700 mm
Ground Clearance 390 mm

New Holland 3230 TX Electrical

Battery 75 Ah
Alternator 35 Amp

New Holland 3230 TX Safety Features

Neutral Safety Switch Yes
ROPS Yes
Clutch Safety Lock Yes

New Holland 3230 TX Other Information

Warranty 6 Year/ 6000 Hours
Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy, Drawbar, Hitch
Additional Features Mobile Charging Port, Fan Belt Guard

New Holland 3230 TX Variants

TractorKarvan Take On New Holland 3230 TX

Good Things
  • Safety: Prioritises operator’s safety with features like clutch safety lock, ROPS and neutral safety switch.
  • Rear Axle: Less stress on gears and shafts due to straight axle planetary drive.
  • Eptra PTO speeds: More PTO speeds for operating various implements.
  • Hydraulics: Similar depth in sowing and ploughing operations due to HP hydraulic with Lift-O-Matic.
Could be Better
  • Could have provided a dry air filter as it cleans air more efficiently than an oil-bath filter.

New Holland 3230 TX Verdict By TractorKarvan

New Holland 3230 TX has a powerful engine that performs excellently in various agricultural operations. High torque and horsepower allow the tractor to handle demanding tasks with ease. Also, this model is fuel-efficient, which results in cost savings over time. It is a versatile tractor that can quickly adapt to different farming needs. Overall, it is a perfect choice for farmers wanting an all-rounder tractor.

Product Review By TractorKarvan

4.6
Overall
5
Performance
4
Transmission
5
Hydraulics
5
Design
4
Ergonomics

New Holland 3230 TX User Reviews

rating star icon 4.5/5
overall
Based on 4 Reviews
4.5
Performance
4.5
Comfort
4.5
Value for Money
4.3
Style & Looks

All Reviews

rating rating rating rating rating
Isme safety ke bhi feature hai
Kafi purana tractor hai mera. 2014 se chala rha hu 7000 ghante chal gaya hai. bhari se bhari kam ispe maine kiye hai. rotavator cultivator thresar chala leta hai to mere sare kam ho jate hai. isme safety ke bhi feature hai jaise neutral switch jisse neutral par hi tractor on hota hai
6 months ago | Jagadeesh Yadav
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 5/5
Style & Looks
Read More
rating rating rating rating rating
Sahi trektar nahi hai
Mujhe ye tractor bilkul pasand nhi aaya, ab mai kubota ka tractor lunga jiski warranty isse do guni jada hai. Ye tractor thik se kam nhi kar raha aur is vajah se mera bahot nuksaan ho gaya.
6 months ago | Benudhar Tiria
Rating Parameters
rating star icon 3/5
Performance
rating star icon 3/5
Comfort
rating star icon 3/5
Value for Money
rating star icon 3/5
Style & Looks
Read More
rating rating rating rating rating
Tractor alag alag upkarno ke sath bahut hi accha kam karta hai
Is tractor ki sabse khas batt ye hai ki ispe tarah tarah ke upkarnan bahut arram se chal jate hai jiski wajah se isse kam karne me bahut asani hoti hai. Maine is tractor ko kheti ke liye hi liya tha aur bahut saare kam karne ke bad mujhe lagta hai ki kheti ke liye isse accha koi nahi hai.
6 months ago | Khimji Premji Makasana
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 4/5
Style & Looks
Read More
rating rating rating rating rating
Ekdum behatarin hai ye kam k mamle me
2011 se istemal kar raha hu or majal h jo is tractor me koi ese dikkat ayi ho jisse mera kaam ruka ho. ekdum behatarin hai ye kam k mamle me
6 months ago | Mukesh Kumar Lodhi
Rating Parameters
rating star icon 5/5
Performance
rating star icon 5/5
Comfort
rating star icon 5/5
Value for Money
rating star icon 5/5
Style & Looks
Read More

Similar To New Holland 3230 TX


New Holland Tractor Dealers & Service Centers

Frequently Asked Questions on New Holland 3230 TX

1. What is the on-road price of New Holland 3230 TX in India 2023?

New Holland 3230 TX price in India 2023 ranges from INR 8 lakhs* to INR 8.60 lakhs*.

New Holland 3230 TX HP is 44 horsepower.

New Holland 3230 TX weighs 1810 kg.

New Holland 3230 TX gear pattern consists of 8 Forward + 2 Reverse and 8 Forward + 8 Reverse Synchro Shuttle.

The fuel tank capacity of New Holland 3230 TX is 46 litres.

New Holland 3230 TX has two steering options, mechanical and power steering.

To get the best financing options for purchasing New Holland 3230 TX, contact Tractorkarvan.

New Holland 3230 TX has two brake options, mechanical and real oil-immersed brakes.

Visit Tractorkarvan to get updated information on New Holland 3230 TX.

New Holland 3230 TX comes in a 2WD option.

New Holland 3230 TX has a lifting capacity of 1800 kg.

There are 3 cylinders in New Holland 3230 TX.

This model comes in single and double clutch options.

The front tyres of this model are 6.00 X 16 / 6.50 X 16, while the rear ones are 13.6 X 28.
