Brand John Deere Tractors
Series E Series Tractors
No. Of Cylinders 3
HP Category 63 HP
Brakes Self Adjusting, Self Equalizing, Hydraulically Actuated Oil Immersed Disc Brake


Key Specifications Of John Deere 5405 Gear Pro Trem IV

Tractor HP
Tractor HP
63 HP
Wheel Drive
Wheel Drive
2WD
Clutch
Clutch
Dry Dual Clutch, Dry Electro-Hydraulic Clutch(Optional)
Steering
Steering
Power Steering
Lifting Capacity
Lifting Capacity
2000 / 2500

About John Deere 5405 Gear Pro Trem IV

John Deere 5405 Gear Pro Trem IV price in India is within the budget of farmers. It delivers a power output of 63 HP.

John Deere 5405 Gear Pro Trem IV Engine

John Deere 5405 Gear Pro Trem IV HP is 63, which is produced at 2100 engine RPM. It is equipped with a 3029H turbocharged engine consisting of 3 cylinders. It also features an HPCR fuel pump and a dry-type air filter.

John Deere 5405 Gear Pro Trem IV Transmission

This tractor’s transmission system consists of a dual dry clutch and a dry electro-hydraulic clutch (optional). It has multiple gear speed options, including 12F + 4R / 12F + 12R / 9F + 3R gears. The gear lever position is on the side shift. It has a top forward speed of 32.6 km/h.

It also features a planetary gear with a straight axle type of rear axle.

John Deere 5405 Gear Pro Trem IV Brakes & Steering

This tractor features self-adjusting, self-equalising, hydraulically actuated oil-immersed disc brakes. It has power steering with tilt steering adjustment.

John Deere 5405 Gear Pro Trem IV PTO & Hydraulics

The PTO speeds offered in this tractor is 540 RPM & 540E / RPTO.

This tractor has a lifting capacity of 2000/2500 kg. It also features ADDC/MQRL/EQRL type of hydraulic controls.

John Deere 5405 Gear Pro Trem IV Tyres

The front tyre size of this tractor is 6.5 X 20 (8 PR) and its rear tyre size is 16.9 X 30/16.9 X 28 (12 PR).

John Deere 5405 Gear Pro Trem IV Weight & Dimensions

The John Deere 5405 Gear Pro Trem IV has a total weight of 2320 kg.

Its wheelbase and ground clearance are 2050 mm and 520 mm, respectively.

John Deere 5405 Gear Pro Trem IV Rivals

Sonalika Tiger DI 65 CRDS and New Holland 5620 TX Plus are some of the direct competitors of John Deere 5405 Gear Pro Trem IV.

John Deere 5405 Gear Pro Trem IV Other Features

The fuel tank capacity of this tractor is 71 litres.

The brand offers a warranty period of 5 years/5000 hours on John Deere 5405 Gear Pro Trem IV.

It comes with a 3.1 m turning radius with brakes.

What is the John Deere 5405 Gear Pro Trem IV Price in India?

The John Deere 5405 price is within a reasonable range for farmers. Its powerful performance and a host of modern features justify the price. However, it is important to note that the final John Deere 5405 on road price may differ in your state and city, as it includes several variable charges like taxes, RTO charges, and insurance. You can learn about the tractor loan process on our tractor loan page if you want to buy this tractor on easy EMI.

Why Choose Tractorkarvan for Information Regarding John Deere 5405 Gear Pro Trem IV?

Tractorkarvan is your one-stop destination for all the information about the John Deere 5405 Gear Pro Trem IV that includes price, features, specifications and more. You can easily find the information you require on Tractorkarvan website. We also provide a tractor compare tractor feature where you can compare the John Deere 5405 price and other specs with other tractor models.

In addition, you can also learn about used John Deere 5405 Gear Pro Trem IV tractors available on our used tractors page. Watch John Deere Videos to get detailed information about different John Deere tractor models.

Read More

John Deere 5405 Gear Pro Trem IV Engine

No. Of Cylinders 3
HP Category 63 HP
Engine Type John Deere 3029H, Turbo Charged, Dual Torque Mode
Engine Rated RPM 2100 RPM
Air Filter Dry Type
Cooling System Liquid Cooled
Fuel Type Diesel
Fuel Pump Type High Pressure Common Rail System (HPCR)
Emission Standard Trem IV

John Deere 5405 Gear Pro Trem IV Transmission

Clutch Dry Dual Clutch, Dry Electro-Hydraulic Clutch(Optional)
Gear Speed 12F + 4R / 12F + 12R / 9F + 3R
Gear Lever Position Side Shift
Forward Speed 1.9 - 32.6, 1.4 - 31.3, 0.35 - 0.87 km/h
Reverse Speed 0.61 - 20, 3.5 - 20, 1.6 - 20 km/h
Brakes Self Adjusting, Self Equalizing, Hydraulically Actuated Oil Immersed Disc Brake
Rear Axle Planetary Gear with Straight Axle

John Deere 5405 Gear Pro Trem IV Steering

Type Power Steering
Adjustment Tilt Steering

John Deere 5405 Gear Pro Trem IV Power Take Off

PTO Speed 540 RPM & 540E / RPTO
RPM 540 @ 1600 ERPM, 516 @ 2100 ERPM

John Deere 5405 Gear Pro Trem IV Fuel Capacity

Capacity 71 Litres

John Deere 5405 Gear Pro Trem IV Hydraulics

Lifting Capacity 2000 / 2500 kg
3 Point Linkage CAT- II
Hydraulics Controls ADDC / Mechanical Quick Rise and Lower (MQRL) /Electrical Quick Rise and Lower (EQRL)
Remote / Auxillary Valve Dual

John Deere 5405 Gear Pro Trem IV Tyre Size

Wheel Drive 2WD
Front 6.5 X 20 (8 PR)
Rear 16.9 X 30 / 16.9 X 28 (12 PR)

John Deere 5405 Gear Pro Trem IV Dimensions And Weight

Total Weight 2320 kg
Wheel Base 2050 mm
Overall Length 3678 mm
Overall Width 2195 mm
Ground Clearance 520 mm
Turning radius with brake 3.1 m

John Deere 5405 Gear Pro Trem IV Electrical

Battery 88 Ah, 12 V
Alternator 40 Amp, 12 V

John Deere 5405 Gear Pro Trem IV Safety Features

ROPS Yes

John Deere 5405 Gear Pro Trem IV Other Information

Warranty 5 Year/ 5000 Hours
Instrument Cluster Digital, LCD Display ( Hour Meter, Tractor Speed and PTO RPM Monitor)
Driver Seat Improved Comfort Seats
Accessories Ballast Weights, Canopy, Canopy Holder, Drawbar, Wagon Hitch, Tow Hook
Additional Features JD Link, Radiator Screen, Floor Mat, Combination Switch, Wider Platform with Rear Floor Extensions, PowrReverser, LED Headlamps

John Deere 5405 Gear Pro Trem IV Variants

You can find the variants of John Deere 5405 Gear Pro Trem IV available on Tractorkarvan with complete specification & prices. Total variant's available 3.

TractorKarvan Take On John Deere 5405 Gear Pro Trem IV

Good Things
  • Powerful 3029H turbocharged engine.
  • Trem IV engine with HPCR fuel pump.
  • Multiple gear speed options with creeper mode.
  • High lifting capacity.
Could be Better
  • The service could be done at authorized John Deere service centers only.

John Deere 5405 Gear Pro Trem IV Verdict

John Deere 5405 Gear Pro Trem IV is a powerful 63 HP tractor, designed to increase productivity with its top-notch hydraulics and robust engine. This tractor is one of the best in its HP class, with a powerful TREM-IV, advanced HPCR engine. It works smoothly even in harsh soil conditions with bigger implements and has additional hydraulic features such as ADDC with MQRL and EQRL. This tractor is unmatched when it comes to back-up torque and comes with different gear speeds and multiple PTO speeds options, so farmers can efficiently carry out multiple applications with a single tractor. The safety and comfort of farmers are also kept in mind with features such as heat guards and ROPS. Consider this tractor if you want a powerful tractor with an appealing look and the latest technology, mainly used for commercial applications.

Product review by TractorKarvan

4.7
Overall
4.5
Power & Performance
4.5
Transmission
5
PTO & Hydraulics
4.5
Design & Styling
5
Ergonomics
