Brand Swaraj Tractors
Series FE Series Tractors
No. Of Cylinders 3
HP Category 66 - 70 HP
Gear Box Synchromesh
Brakes Oil Immersed Multi Disc Brakes


Key Specifications Of Swaraj 969 FE

Tractor HP
Tractor HP
66 - 70 HP
Wheel Drive
Wheel Drive
2WD
Clutch
Clutch
Mechanically Actuated Double Clutch
Gear Box
Gear Box
Synchromesh
Steering
Steering
Power Steering
Lifting capacity
Lifting capacity
2200

About Swaraj 969 FE

Swaraj 969 FE price in India ranges from INR 8.96 lakhs* to INR 9.45 lakhs*. Swaraj 969 FE HP is noted to be 66 to 70 horsepower. The engine capacity of the tractor is 3478 cc.

Swaraj 969 FE is an incredible tractor from the Swaraj FE series that is ahead of many competitors. As it belongs to the tractors under 70 HP category, this tractor is a powerful beast. Additionally, the Swaraj 969 FE tractor price is within the tractors above 9 lakhs category due to the features it offers.

Let us discuss Swaraj 969 FE in detail, including Swaraj 969 FE tractor price, key features, benefits, warranty, and more.

Swaraj 969 FE Top Specifications

Engine & Performance

  • The HP of Swaraj 969 is 66-70 HP, which is produced when engine crankshaft rotates at 2000 RPM. Powered by 3 cylinders and an engine capacity of 3478 cc, it can handle various heavy-duty farm tasks and operate large tractor implements with ease.
  • The tractor features a dry-type air filter so that only clean air enters the engine’s internal combustion process, improving its performance.
  • The cooling system provided in this tractor is liquid-cooled with no loss tank. This system effectively removes excessive heat from the engine, thereby extending its lifespan.
  • The bore/stroke of this tractor is 110 X 122 mm. This ideal ratio enables it to generate a higher torque at lower fuel consumption, making it capable of handling demanding tasks with ease.

Transmission

  • Swaraj 969 features a mechanically actuated double clutch to efficiently transmit engine power to the rear axle and PTO independently.
  • It has the most advanced synchromesh gearbox for smooth and easy gear change. This gearbox is durable and has a longer lifespan.
  • Swaraj 969 FE gear pattern is 12 forward + 3 reverse gears. These gears enable the operator to attain the appropriate speed according to the requirements of the farming task or the terrain.
  • This tractor has a side shift gear lever. The operator prefers this gear lever position as it is easy to reach and thus facilitates easier gear changes.
  • It also has a planetary reduction rear axle, which helps lower power transmission loss and adds to its sturdiness.

Hydraulics

  • Swaraj 969 lifting capacity is 2200 kg enabling the tractor to lift heavy implements like Laser Land Leveler and Cutter Mixer Feeder.
  • The tractor features Automatic Depth & Draft Control (ADDC) hydraulic controls enabling the tractor to automatically adjust the draft and depth of implements. This feature ensures a consistent working depth across the entire field, enhancing overall efficiency.
  • It comes with a dual remote/auxiliary valve. This valve allows hydraulic implements to operate seamlessly, enhancing productivity.

Weight & Dimensions

  • Swaraj 969 weight is 2690 kg, and the wheelbase is 2210. As a result, the tractor performs operations on even rough terrain with greater stability and traction.
  • The ground clearance is 367 mm. The ground clearance of the tractor enables smooth operations in diverse field conditions, including uneven terrains, stubble, or crop residues.
  • The length and width of this tractor are 3705 mm and 1915 mm, respectively. Due to its appropriate size, this model can manoeuvre with stability in all types of field conditions.

Brakes & Steering

  • Swaraj 969 FE has oil-immersed disc brakes. The effective cooling and lubrication provided by the oil enable these brakes to deliver excellent braking performance.
  • Swaraj 969 FE features power steering for better control while working on rugged fields. Compared to mechanical steering, power steering demands less effort from the operator, resulting in better handling capabilities.

Wheel Drive & Tyres

  • The tractor comes in a 2-wheel-drive variant. This makes it more budget-friendly compared to four-wheel drive tractors.
  • The front tyre size of Swaraj 969 measures 7.50 X 16, while the rear tyres measure 16.9 X 28.

Swaraj 969 FE Additional Features

  • It comes with multiple accessories like tools, bumper, ballast weight, top link, canopy, drawbar, and hitch.
  • Swaraj 969 FE has a PTO speed of 540 RPM and 540 ERPM. The mileage of Swaraj 969 is excellent due to the economy PTO speed. It saves fuel by operating at a lower ERPM.
  • It has a 100 Ah, 12 Volts battery, which is powerful enough to power all the electrical components of the tractor for a long time.

Swaraj 969 FE Warranty

Swaraj 969 FE comes with a warranty period of 2 years/ 2000 hours, whichever comes earlier. Swaraj offers almost the same warranty on all its tractor models.

Swaraj 969 FE Price in India 2024

The Swaraj 969 FE price in India ranges from INR 8.96 lakhs* to INR 9.45 lakhs*, with EMI starting at INR 23,020, if you are using the tractor loan facility of Tractorkarvan. Swaraj 969 FE tractor price justifies the features it contains, and that is why farmers widely prefer it. Swaraj 969 FE tractor is highly dependable, demands low maintenance, and results in better profits.

To compare the Swaraj 969 FE tractor price with other Swaraj models, use the compare tractors tool on Tractorkarvan. For example, comparable models include Swaraj 960 FE and Swaraj 963 FE.

Why choose Tractorkarvan for Swaraj 969 FE?

Tractorkarvan is a well-known platform that helps farmers buy the upcoming modelslatest tractors and other farm equipment. If you are facing a challenge in managing funds for a new tractor, feel free to check out second-hand Swaraj tractors. With accurate information and easy financing, Tractorkarvan is the ideal platform for all your tractor-related needs. Get in touch with Swaraj tractor dealers today.

Read More

Swaraj 969 FE Engine

No. Of Cylinders 3
HP Category 66 - 70 HP
Engine Type 4 Stroke, Direct injection, Turbocharged
Engine Rated RPM 2000 RPM
Capacity 3478 CC
Air Filter Dry Type
Cooling System Liquid Cooled
Fuel Type Diesel
Bore / Stroke 110 / 122 mm

Swaraj 969 FE Transmission

Clutch Mechanically Actuated Double Clutch
Gear Box Synchromesh
Gear Speed 12 Forward + 3 Reverse
Gear Lever Position Side Shift
Forward Speed 2.70 to 33.50 km/h
Reverse Speed 3.30 to 12.90 km/h
Brakes Oil Immersed Multi Disc Brakes
Rear Axle Planetary Reduction

Swaraj 969 FE Steering

Type Power Steering

Swaraj 969 FE Power Take Off

PTO Speed 540, 540E, Multispeed PTO, IPTO

Swaraj 969 FE Hydraulics

Lifting capacity 2200 kg
3 Point Linkage CAT- II
Hydraulics Controls ADDC
Remote / Auxillary Valve Dual

Swaraj 969 FE Tyre Size

Wheel Drive 2WD
Front 7.50 X 16
Rear 16.9 X 30

Swaraj 969 FE Dimensions And Weight

Total Weight 2850 kg
Wheel Base 2210 mm
Overall Length 3705 mm
Overall Width 1915 mm
Ground Clearance 407 mm

Swaraj 969 FE Electrical

Battery 12 V, 100 Ah

Swaraj 969 FE Safety Features

Neutral Safety Switch Yes

Swaraj 969 FE Other Information

Warranty 2 Year/ 2000 Hours
Instrument Cluster Digital
Driver Seat Comfortable Seat
Accessories Tools, Bumper, Ballast Weight, Top Link, Canopy, Drawbar, Hitch
Additional Features Easy Hitch Lever, Multi Reflector Lights, Single Piece Bonnet, 400 Hours Service Interval

Swaraj 969 FE Variants

There are 1 Variants of Swaraj 969 FE available on Tractorkarvan with complete specification and prices.

TractorKarvan Take On Swaraj 969 FE

Good Things
  • Silencer: Adjustable silencer allows easy access in orchards.
  • Rear Axle: Planetary reduction ensures low maintenance and longer life.
  • Double Clutch: Offers smoother transmission with uninterrupted PTO operation.
  • Hydraulics: Can operate heavy implements and maintain uniform working depth.
  • Feature-rich: Equipped with various useful features like Single Piece Bonnet, Multi Reflector Lights and Easy Hitch Lever.
Could be Better
  • Could have provided more PTO speed options for operating a wider range of implements and better efficiency.

Swaraj 969 FE Verdict

The 969 FE is a powerful model tailored for heavy-duty farming activities. It boasts numerous features, including an adjustable silencer, easy gear shifting, and higher capacity hydraulics, which make tasks like planting and seed drilling a breeze. With impressive speed and a superior gear system, this tractor ensures seamless operations for all farm tasks. In summary, Swaraj 969 FE is an excellent choice for farmers in search of a robust tractor.

Product review by TractorKarvan

4.8
overall
4.5
Power & Performance
5
Transmission
5
PTO & Hydraulics
4.5
Design & Styling
5
Ergonomics

Swaraj 969 FE User Reviews

No Reviews found. Be the first one to review!

Similar Used Tractors

Swaraj 969 FE Second Hand Tractor
969 FE
Swaraj
2022 | Price ₹8.20 Lakh
Ballia, Uttar Pradesh
Get More Details

Similar Brands


Similar To Swaraj 969 FE

Same Deutz Fahr Agrolux 70 4WD Tractor
Agrolux 70 4WD
Same Deutz Fahr
70 HP 4WD
Get More Details
Preet 6549 4WD Tractor
6549 4WD
Preet
65 HP 4WD
Get More Details
Solis 6524 S Tractor
6524 S
Solis
65 HP 2WD
Get More Details

Suitable Implements

Vishwakarma C309 Cultivator Implement
C309
Vishwakarma
Cultivator
35+ HP

Get More Details
Farmpower 3 Bottom MB Plough Hydraulic Reversible MB Plough Implement
3 Bottom MB Plough
Farmpower
Hydraulic Reversible MB Plough
42+ HP

Get More Details
Santhosh 555 Rotavator Implement
555
Santhosh
5 Feet Rotavator
35+ HP

Get More Details
Jaysan Hyper JRT166H Rotavator Implement
Hyper JRT166H
Jaysan
6 Feet Rotavator
50+ HP

Get More Details

Suitable Tyres

5

Yrs
Certified
BIRLA 7.50-16 Shaan Tyre
7.50-16 Shaan
BIRLA Tyres
Front TyreSize - 7.50 X 16
Get More Details
7

Yrs
Certified
JK Sona 7.50-16 Tyre
Sona 7.50-16
JK Tyres
Front TyreSize - 7.50 X 16
Get More Details
BKT 7.50-16 Commander Twin Rib Tyre
7.50-16 Commander Twin Rib
BKT Tyres
Front TyreSize - 7.50 X 16
Get More Details
2

Yrs
Certified
APOLLO 16.9-30 Krishak Premium Drive Tyre
16.9-30 Krishak Premium Drive
APOLLO Tyres
Rear TyreSize - 16.90 X 30
Get More Details

Swaraj Tractor Dealers & Service Centers

Neemtala Chowk barsoi, Katihar, Katihar, Bihar - 855102
+91-*******277
Contact Dealer
Molana Abul Kalam Azad Chowk Zero Mile, Araria, Araria, Bihar - 854311
+91-*******908
Contact Dealer
Jahanvi Chowk, Naugachhia, Bhagalpur, Bihar - 853204
+91-*******046
Contact Dealer
Bheria Rahika, Mojheli, Katihar, Katihar, Bihar - 854105
+91-*******205
Contact Dealer
Mp Tiwari Campus, near Congress Office, Supaul, Supaul, Bihar - 852131
+91-*******557
Contact Dealer
Near Police Line Ward No.4, Pipra Road Supaul, Supaul, Supaul, Bihar - 852131
+91-*******578
Contact Dealer

Frequently Asked Questions On Swaraj 969 FE

1. What is the on road price of Swaraj 969 in India 2024?

The on-road Swaraj 969 FE price in India 2024 ranges from INR 8.96 lakhs* to INR 9.45 lakhs*.

Swaraj 969 HP range is 66 to 70.

Swaraj 969 weight is 2690 kg.

The gear pattern of Swaraj 969 includes 12 Forward + 3 Reverse gears.

Swaraj 969 has a fuel tank capacity of 60 litres.

Swaraj 969 comes with power steering.

Tractorkarvan provides finance for purchasing Swaraj 969.

Swaraj 969 includes oil-immersed multi-disc brakes.

The updated information on Swaraj 969 is present on Tractorkarvan.

Swaraj 969 comes in a 2WD variant.

The lifting capacity of Swaraj 969 is 2200 kg.

Swaraj 969 comes with 3 cylinders.

Swaraj 969 features a mechanically actuated single clutch.

Swaraj 969 has front and rear tyres in sizes 7.5 X 16 and 16.9 X 28, respectively.
