John Deere 5075 Gear Pro Trem IV

Brand John Deere Tractors
Series E Series Tractors
No. Of Cylinders 3
HP Category 74 HP
Gear Box Top Shaft Synchromesh (TSS)
Brakes Self Adjusting, Self Equalizing, Hydraulically Actuated Oil Immersed Disc Brake


Key Specifications Of John Deere 5075 Gear Pro Trem IV

Tractor HP
Tractor HP
74 HP
Wheel Drive
Wheel Drive
2WD
Clutch
Clutch
Dry Dual Clutch, Dry Electro-Hydraulic Clutch(Optional)
Gear Box
Gear Box
Top Shaft Synchromesh (TSS)
Steering
Steering
Power Steering
Lifting capacity
Lifting Capacity
2500

About John Deere 5075 Gear Pro Trem IV

John Deere 5075 Gear Pro Trem IV price in India justifies its features and performance. The John Deere 5075 Gear Pro Trem IV HP is 74.

What are the key features of the John Deere 5075 Gear Pro Trem IV?

Engine

This John Deere tractor generates 74 HP power when its engine operates at 2100 RPM. It has a turbocharged dual torque mode engine that features 3 cylinders. It also comes with a liquid-cooled cooling system and a dry-type dual-element air filter.

Transmission

Its transmission system has a dry dual-clutch/electro-hydraulic clutch (optional) and top shaft synchromesh (TSS) gearbox. It has three gear speed options: 9F + 3R (Creeper) / 12F + 4R / 12F + 12R gear speeds. Its gear lever is positioned at the side shift.

Brakes & Steering

This tractor is equipped with self-adjusting, self-equalizing, hydraulically actuated oil-immersed disc brakes and power steering.

PTO & Hydraulics

The PTO speeds offered in this tractor are standard 540 RPM & 540E @ 1600 ERPM and RPTO (optional).

This John Deere tractor has a lifting capacity of 2500 kg. It also features ADDC-type hydraulic controls and a dual remote/auxillary valve.

Fuel Capacity & Tyres

The fuel tank capacity of this tractor is 71 litres.

The tractor’s rear tyre size is 18.4 X 30, respectively.

Weight & Wheelbase

John Deere 5075 Gear Pro Trem IV has a total weight of 2450 kg.

It comes with a wheelbase of 2050 mm.

Warranty

John Deere provides 5-year / 5000-hour warranty on John Deere 5075 Gear Pro tractors.

Rivals

The John Deere 5075 Gear Pro Trem IV is a 74 HP tractor and faces competition with the New Holland 5630 TX Plus and Sonalika Tiger DI 75 CRDS 2WD.

Additional Features

This tractor has many additional features, such as an AC cabin, radiator screen, LED headlamps, floor mat, and many others.

What is the John Deere 5075 Gear Pro Trem IV Price in India 2024?

The John Deere 5075 Gear Pro Trem IV price in India is set based on its features. To know the on-road price, contact us now.

What are the alternatives for John Deere 5075 Gear Pro Trem IV on Tractorkarvan?

Tractorkarvan is a popular platform specially created to help farmers get complete information on the John Deere 5075 Gear Pro Trem IV tractor easily. Here, we have provided its specifications. If you are looking to buy this tractor on loan, then use our tractor loan facility. We offer loans on both new and second-hand John Deere tractors.

Read More

John Deere 5075 Gear Pro Trem IV Engine

No. Of Cylinders 3
HP Category 74 HP
Engine Type John Deere 3029H, Turbo Charged, Dual Torque Mode
Engine Rated RPM 2100 RPM
Air Filter Dry Type, Dual Element
Cooling System Liquid Cooled
Fuel Type Diesel
Fuel Pump Type High Pressure Common Rail System (HPCR)
Emission Standard Trem IV

John Deere 5075 Gear Pro Trem IV Transmission

Clutch Dry Dual Clutch, Dry Electro-Hydraulic Clutch(Optional)
Gear Box Top Shaft Synchromesh (TSS)
Gear Speed 9F + 3R (Creeper) / 12F + 4R / 12F + 12R
Gear Lever Position Side Shift
Forward Speed 1.9 - 32.6 km/h
Reverse Speed 3.7 - 20 km/h
Brakes Self Adjusting, Self Equalizing, Hydraulically Actuated Oil Immersed Disc Brake
Rear Axle Planetary Gear with Straight Axle

John Deere 5075 Gear Pro Trem IV Steering

Type Power Steering
Adjustment Tilt Steering

John Deere 5075 Gear Pro Trem IV Power Take Off

PTO Speed 540 RPM & 540E / RPTO (Optional)
RPM 540 RPM @ 1600 ERPM

John Deere 5075 Gear Pro Trem IV Fuel Capacity

Capacity 71 Litres

John Deere 5075 Gear Pro Trem IV Hydraulics

Lifting Capacity 2500 kg
3 Point Linkage CAT- II
Hydraulics Controls ADDC / Mechanical Quick Rise and Lower (MQRL) /Electrical Quick Rise and Lower (EQRL)
Remote / Auxillary Valve Dual

John Deere 5075 Gear Pro Trem IV Tyre Size

Wheel Drive 2WD
Front 12.4 X 24
Rear 18.4 X 30

John Deere 5075 Gear Pro Trem IV Dimensions And Weight

Total Weight 2450 kg
Wheel Base 2050 mm
Overall Length 3678 mm
Overall Width 1982 mm
Ground Clearance 520 mm
Turning radius with brake 3.1 m

John Deere 5075 Gear Pro Trem IV Safety Features

ROPS Yes

John Deere 5075 Gear Pro Trem IV Other Information

Warranty 5 Year/ 5000 Hours
Instrument Cluster Digital, Multi Function Display
Driver Seat Improved Comfort Seats
Accessories Ballast Weights, Canopy, Canopy Holder, Drawbar, Wagon Hitch, Tow Hook
Additional Features AC Cabin, JD Link, Radiator Screen, Floor Mat, Combination Switch, Wider Platform with Rear Floor Extensions, PowrReverser, LED Headlamps

John Deere 5075 Gear Pro Trem IV Variants

There are 3 Variants of John Deere 5075 Gear Pro Trem IV available on Tractorkarvan with complete specification and prices.

TractorKarvan Take On John Deere 5075 Gear Pro Trem IV

Good Things
  • Turbocharged engine with dual torque mode.
  • Multiple gear speed options for different farming operations.
Could be Better
  • Could have offered double clutch.

John Deere 5075 Gear Pro Trem IV Verdict

John Deere 5075 Gear Pro Trem IV is a heavy-duty tractor suitable for large farmlands. It comes with a 74 HP engine and delivers high power and performance during any field application. Its lifting is exceptional. The synchro shuttle gearbox allows forward and reverse movement at the same speed. Its robust build quality makes it a long-lasting tractor. Its forward speed is excellent on the roads, which also makes it suitable for haulage work. Overall, this tractor is an ideal choice for medium and large farms.

Product review by TractorKarvan

4.7
overall
4.5
Power & Performance
4.5
Transmission
5
PTO & Hydraulics
4.5
Design & Styling
5
Ergonomics
